Driverless

Yes

Number of Screen Outputs

3

Video ports

DisplayPort++, HDMI, VGA

Maximum resolution

4K

Power delivery

100W

Operating system(s)

Windows

Number of USB ports

5

USB fast charging

Yes

Docking station family

The Task Master

DockWorks

Yes (for Windows only)

Best For

USB-C Laptops & Ultrabooks that support Power Delivery and Monitors that support up to 4K

Compatibility

Windows 10 or above

Card Reader

SD Cards and Micro SD card slots (UHS-I, SD3.0)

USB-A ports

4 x: (2) USB 3.2 Gen2 (front) with 5V/0.9A (2) USB 2.0 (back)

USB-C ports

1 x USB-C 3.2 Gen2 (front) with 5V/1.5A charging

Audio

1 x 3.5mm Combo Microphone & Headphone Port (front)

Data transfer speeds

Supports up to 10Gbps data transfer speed

Ethernet Speed (Mbps)

10, 100, 1000 Actual Ethernet speeds may vary depending on, but not limited to, Internet bandwidth, Ethernet cables, network switches, and the hardware and firmware performance of the host computer.

Maximum resolution supported

Minimum Resolution (DP1.2/HBR2): Single 4K @ 30Hz Dual 1080p @ 60Hz Triple 1600x900 @ 60Hz // Maximum Resolution (DP1.4/HBR3): Single 4K @ 60Hz Dual 4K @ 60Hz Triple 1080p @ 60Hz

Plug & play

Plug & play installation without need for drivers or downloads

System requirements

Host device must support Power Delivery and DisplayPort Alt Mode over USB-C

USB-C Power Delivery

Supports USB-C PD 3.0 (100W of laptop charging)

Video output

1 x DisplayPort++ v1.4, 1 x VGA, 2 x HDMI v2.0

4K support

Yes
