Connection technology | Thunderbolt™ 4, USB-C Alt Mode and USB-C (DisplayLink) |
Driverless | No |
Number of Screen Outputs | 4 |
Video ports | DisplayPort, HDMI, Thunderbolt 4 |
Maximum resolution | 8K |
Power delivery | 96W |
Operating system(s) | Chrome OS, macOS, Windows |
Number of USB ports | 4 |
USB fast charging | Yes |
Docking station family | The Innovator |
DockWorks | Yes (for Windows only) |
Best For | M1/M2/M3/M4 MacBook Air and MacBook Pro, Windows or Chrome OS laptop with a Thunderbolt port |
Compatibility | Chrome OS 116 or above, macOS 11 or above, Windows 10 or above |
Card Reader | SD Cards and Micro SD card slots (UHS-II, SD4.0) |
USB-A ports | 1 x USB 3.2 Gen2 (front) with 5V/1.5A, 2 x USB 3.2 Gen1 (back) with 5V/0.9A |
USB-C ports | 1 x USB 3.2 Gen2 (front) with up to 5V/3A |
Audio | 1 x 3.5mm Combo Microphone & Headphone Port (front) |
Data transfer speeds | Supports up to 40Gbps data transfer speed |
Ethernet Speed (Mbps) | 10, 100, 1000, 2500 Actual Ethernet speeds may vary depending on, but not limited to, Internet bandwidth, Ethernet cables, network switches, and the hardware and firmware performance of the host computer. |
Maximum resolution supported | Up to Quad 4K @ 60Hz, Single 8K @ 60Hz |
Plug & play | Video options (3), (4), and (5) support up to two plug-and-play displays. Video options (1) and (2) require DisplayLink driver installation. |
Security slot compatibility | Kensington Nano Security Slot, Kensington Security Slot |
System requirements | Thunderbolt 4, USB4, and USB-C Alt Mode devices |
Thunderbolt Ports | 3 x Thunderbolt 4 Ports (1 x upstream and 2 x downstream) |
USB-C Power Delivery | Supports USB-C PD 3.0 (96W of laptop charging) |
Video output | 1 x DisplayPort v1.4, 2 x DisplayPort v1.2, 2 x HDMI v2.0, Thunderbolt 4 ports |
4K support | Yes |
