Interface

PCIe 5.0 x4 NVMe

Capacity

1TB

Controller

SM2508

NAND

3D TLC

DRAM Cache

Yes

DirectStorage Supported

Yes

Sequential Read/Write¹

Up to 14,800/14,000MB/s

Random 4K Read/Write¹

Up to 2,200,000/2,200,000 IOPS

Endurance (Total bytes written)³

4.0PB

Power Consumption⁴

0.27W Avg / 7.1W @ 14.8G / 9.5W (MAX)

Storage Temperature

-40°C~85°C

Operating Temperature

0°C~70°C

Dimensions

80mm x 22mm x 2.3mm

Weight

7.7g

Vibration Operating

2.17G Peak (7-800Hz)

Vibration Non-operating

20G Peak (20-1000Hz)

MTBF

2,000,000 hours

Notes

This SSD is designed for use in desktop and notebook computer workloads and is not intended for Server environments.

1. Based on “Fresh out-of-box performance”, Sequential R/W using PCIe 5.0 Ryzen5 7600X CPU and X670E Motherboard, Random R/W using Intel Ultra7 and Z890 Motherboard. Speed may vary due to host hardware, software, and usage.

2. Some of the listed capacity on a Flash storage device is used for formatting and other functions and thus is not available for data storage. As such, the actual available capacity for data storage is less than what is listed on the products. For more information, go to Kingston's Flash Memory Guide.

3. Total Bytes Written (TBW) is derived from the JEDEC Client Workload (JESD219A).

4. Average power consumption is based on Mobilemark™ workload. Max power consumption is based on typical value.
