PERFORMANCE |
Processor | IntelĀ® Core Ultra 5 225U, 12C (2P + 8E + 2LPE) / 14T, Max Turbo up to 4.8GHz, 12MB |
AI PC Category | AI PC |
NPU | Integrated IntelĀ® AI Boost, up to 12 TOPS |
Graphics | Integrated IntelĀ® Graphics |
Chipset | IntelĀ® SoC Platform |
Memory | 2x 8GB SO-DIMM DDR5-5600 |
Memory Slots | Two DDR5 SO-DIMM slots, dual-channel capable |
Max Memory | Up to 64GB DDR5-5600 |
Storage | 512GB SSD M.2 2242 PCIeĀ® 4.0x4 NVMeĀ® |
Storage Slot | Two M.2 2280 PCIeĀ® 4.0 x4 slots |
Max Storage Support | Up to two drives, 2x M.2 SSD ā¢ M.2 2280 SSD up to 2TB each |
Card Reader | SD Card Reader |
Audio Chip | High Definition (HD) Audio, RealtekĀ® ALC3287 codec |
Speakers | Stereo speakers, 2W x2, Dolby Audioā¢ |
Microphone | 2x, Array |
Camera | FHD 1080p + IR Hybrid with Privacy Shutter |
Battery | 45Wh |
Power Adapter | 65W USB-CĀ® (3-pin) |
Special Features | Modern Standby |
DESIGN |
Display | 14" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC, 60Hz |
Touchscreen | None |
Screen-to-Body Ratio | 90% |
Color Calibration | None |
Pen | Pen Not Supported |
Keyboard | Backlit, English |
Touchpad | Buttonless MylarĀ® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches) |
Dimensions (WxDxH) | 313.5 x 224 x 17.5 mm (12.34 x 8.82 x 0.69 inches) |
Weight | Starting at 1.36 kg (2.99 lbs) |
Case Color | Arctic Grey |
Case Material | Aluminium (Top), PC-ABS (Bottom) |
Surface Treatment | Anodizing Sandblasting (Top), Texture (Bottom) |
SOFTWARE |
Operating System | WindowsĀ® 11 Pro, English (US) / English (UK) |
Bundled Software | Office Trial |
CONNECTIVITY |
WLAN + Bluetooth | Wi-FiĀ® 6E, 802.11ax 2x2 + BT5.3 |
WWAN | Non-WWAN |
Ethernet | 100/1000M (RJ-45) |
Standard Ports | 1x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On 1x USB-CĀ® (USB 10Gbps / USB 3.2 Gen 2), with USB PD 3.0 and DisplayPortā¢ 1.4 1x USB-CĀ® (Thunderboltā¢ 4 / USB4Ā® 40Gbps), with USB PD 3.0 and DisplayPortā¢ 2.1 1x HDMIĀ® 2.1, up to 4K/60Hz 1x Headphone / microphone combo jack (3.5mm) 1x Ethernet (RJ-45) 1x SD card reader |
Docking | Various docking solutions supported via Thunderboltā¢ or USB-CĀ®. For more compatible docking solutions, please visit Docking for ThinkBookĀ® 14 G8 IAL |
SECURITY & PRIVACY |
Security Chip | Firmware TPM 2.0 Enabled |
Physical Locks | KensingtonĀ® Nano Security Slot, 2.5 x 6 mm |
Fingerprint Reader | Touch Style, Match-on-Chip, Integrated in Power Button |
Other Security | Camera privacy shutter IR camera for WindowsĀ® Hello (facial recognition) |
MANAGEABILITY |
System Management | Non-vProĀ® |
ACCESSORIES |
Bundled Accessories | None |
CERTIFICATIONS |
Green Certifications | ENERGY STARĀ® 9.0 EPEATā¢ Gold Registered ErP Lot 6/26 RoHS compliant TCO Certified 10.0 |
Mil-Spec Test | MIL-STD-810H military test passed |
Other Certifications | TĆV RheinlandĀ® Low Blue Light (Software Solution) |
