PERFORMANCE |
Processor | IntelĀ® Core i5-13420H, 8C (4P + 4E) / 12T, P-core up to 4.6GHz, E-core up to 3.4GHz, 12MB Intel Smart Cache |
Graphics | Integrated IntelĀ® UHD Graphics |
Chipset | IntelĀ® SoC Platform |
Memory | 2x 8GB SODIMM DDR5-5600 |
Memory Slots | Two DDR5 SODIMM slots, dual-channel capable |
Max Memory | Up to 64GB DDR5-5600 |
Storage | 512GB SSD M.2 2280 PCIeĀ® 4.0x4 NVMeĀ® Opal 2.0 |
Max Storage Support | Up to two drives, 2x M.2 SSD ā¢ M.2 SSD up to 1TB each |
RAID Preset | None |
Card Reader | No card reader |
Optical | None |
Audio Chip | High Definition (HD) Audio, RealtekĀ® ALC256 codec |
Speakers | 2Wx1 |
Camera | No camera |
Microphone | No microphone |
Power Supply | 90W 89% Adapter |
DESIGN |
Keyboard | USB, Calliope, Black, English (US) |
Mouse | USB Calliope Mouse, Black |
Optional Bay | None |
Expansion Slots | Three M.2 slots (one for WLAN, two for SSD) |
Case Color | Black |
Stand | None |
Adapter Cage | None |
Toolless Chassis Screw | None |
Mounting | None |
IO Box | No IO box |
Pen | Pen Not Supported |
Form Factor | Tiny (1L) |
Dimensions (WxDxH) | Tiny only (without rubber feet) | 179 x 182.9 x 34.5 mm (7.05 x 7.2 x 1.36 inches) Tiny only (with rubber feet) | 179 x 182.9 x 36.5 mm (7.05 x 7.2 x 1.44 inches) |
Weight | Around 1.13 kg (2.49 lbs) |
CONNECTIVITY |
WLAN + Bluetooth | IntelĀ® Wi-FiĀ® 6E AX211, 802.11ax 2x2 + BT5.3 |
WWAN | Non-WWAN |
Ethernet | Integrated 100/1000M |
Front Ports | 1x USB-CĀ® (USB 10Gbps / USB 3.2 Gen 2), with data transfer and 5V@3A charging 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), with Always On and 5V@2.1A charging 1x headphone / microphone combo jack (3.5mm) |
Rear Ports | 2x USB-A (Hi-Speed USB / USB 2.0), one supports Smart Power On 2x USB-A (USB 10Gbps / USB 3.2 Gen 2) 1x HDMIĀ® 2.1 TMDS 1x DisplayPortā¢ 1.4b 1x Ethernet (GbE RJ-45) 1x Power connector |
Optional Rear Ports (configured) | DP 1.4 |
Monitor Cable | None |
SECURITY & PRIVACY |
Security Chip | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
Fingerprint Reader | No fingerprint reader |
Physical Locks | KensingtonĀ® Security Slotā¢, 3 x 7 mm |
Chassis Intrusion Switch | Chassis Intrusion Switch |
MANAGEABILITY |
System Management | Non-vProĀ® |
CERTIFICATIONS |
Green Certifications | ENERGY STARĀ® 9.0 RoHS compliant TCO Certified, generation 10 |
SOFTWARE |
Operating System | WindowsĀ® 11 Pro, English |
Bundled Software | None |
ACCESSORIES |
Bundled Accessories | None |
