PERFORMANCE |
Processor | Intel® Core™ i7-1270P, 12C (4P + 8E) / 16T, P-core 2.2 / 4.8GHz, E-core 1.6 / 3.5GHz, 18MB |
Graphics | NVIDIA® Quadro® T550 4GB GDDR6 |
Chipset | Intel® SoC Platform |
Memory | 16GB Soldered DDR4-3200 Non-ECC + 16GB SO-DIMM DDR4-3200 Non-ECC |
Memory Slots | One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable |
Max Memory | Up to 48GB (16GB soldered + 32GB SO-DIMM) DDR4-3200 |
Storage | 1TB SSD M.2 2280 PCIe® x4 NVMe® Opal 2.0 |
Storage Support | One drive, up to 2TB M.2 2280 SSD |
Storage Slot | One M.2 2280 PCIe® 4.0 x4 slot |
Card Reader | No card reader |
Optical | None |
Audio Chip | High Definition (HD) Audio, Realtek® ALC3287 codec |
Speakers | Stereo speakers, Dolby® Audio™ |
Camera | FHD 1080p + IR with Privacy Shutter |
Microphone | 2x, Array |
Battery | Integrated 52.5Wh |
Power Adapter | 100W USB-C® Slim (3-pin) |
DESIGN |
Display | 16" WQXGA (2560x1600) IPS 400nits Anti-glare, 100% sRGB, Dolby® Vision™, TÜV Eye Comfort |
Touchscreen | None |
Color Calibration | Factory Color Calibration |
Keyboard | Backlit, English |
Case Color | Black |
Case Material | PC + 20% CF + 50% GF (Top), PPS (Bottom) |
Dimensions (WxDxH) | 361.9 x 255.5 x 21.1 mm (14.25 x 10.06 x 0.83 inches) |
Weight | Starting at 1.8 kg (3.97 lbs) |
SOFTWARE |
Operating System | Windows® 11 DG Windows 10 Pro 64, English |
Bundled Software | None |
CONNECTIVITY |
Ethernet | 100/1000M (RJ-45) |
WLAN + Bluetooth | Intel® Wi-Fi® 6E AX211, 11ax 2x2 + BT5.1 |
WWAN | Fibocom L860-GL-16, 4G LTE CAT16 |
SIM Card | None |
NFC | NFC |
Standard Ports | 1x Ethernet (RJ-45) 1x HDMI® 2.1, up to 4K/60Hz 1x Headphone / microphone combo jack (3.5mm) 1x Security keyhole 2x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 2.0) 2x USB 3.2 Gen 1 (one Always On) |
Docking | Various docking solutions supported via Thunderbolt™ or USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad® P16s Gen 1 (Intel®) |
Monitor Cable | None |
SECURITY & PRIVACY |
Smart Card Reader | None |
Security Chip | Discrete TPM 2.0 Enabled |
Fingerprint Reader | Touch Style, Match-on-Chip, Integrated in Power Button |
Physical Locks | Kensington® Nano Security Slot™, 2.5 x 6 mm |
Other Security | IR camera for Windows® Hello |
MANAGEABILITY |
System Management | Intel® vPro® Enterprise |
ACCESSORIES |
Bundled Accessories | None |
CERTIFICATIONS |
Green Certifications | ENERGY STAR® 8.0 EPEAT™ Gold Registered TCO Certified 9.0 RoHS compliant |
Other Certifications | TÜV Rheinland® Eye Comfort Certification TÜV Rheinland® Low Blue Light |
Mil-Spec Test | MIL-STD-810H military test passed |
ISV Certifications | Please visit ISV certifications for Lenovo® Workstations |
