PERFORMANCE |
Processor | IntelĀ® Core Ultra 5 125U, 12C (2P + 8E + 2LPE) / 14T, Max Turbo up to 4.3GHz, 12MB |
AI PC Category | AI PC |
NPU | Integrated IntelĀ® AI Boost, up to 11 TOPS |
Graphics | Integrated IntelĀ® Graphics |
Chipset | IntelĀ® SoC Platform |
Memory | 2x 8GB SO-DIMM DDR5-5600 |
Memory Slots | Two DDR5 SO-DIMM slots, dual-channel capable |
Max Memory | Up to 64GB DDR5-5600 |
Storage | 512GB SSD M.2 2280 PCIeĀ® 4.0x4 NVMeĀ® Opal 2.0 |
Storage Slot | One M.2 2280 PCIeĀ® 4.0 x4 slot |
Max Storage Support | One drive, up to 2TB M.2 2280 SSD |
Optical | None |
Card Reader | None |
Audio Chip | High Definition (HD) Audio, Senary SN6147 codec |
Speakers | Stereo speakers, 2W x2, Dolby Audioā¢ |
Microphone | 2x, Array |
Camera | 5.0MP + IR Discrete with Privacy Shutter |
Battery | 46.5Wh |
Power Adapter | 65W USB-CĀ® (3-pin) |
DESIGN |
Display | 16" WUXGA (1920x1200) IPS 300nits Anti-glare, 45% NTSC |
Touchscreen | None |
Screen-to-Body Ratio | 87% |
Pen | Pen Not Supported |
Keyboard | Non-backlit, English |
Dimensions (WxDxH) | 357.2 x 253.4 x 20.78 mm (14.06 x 9.98 x 0.82 inches) |
Weight | Starting at 1.77 kg (3.90 lbs) |
Case Color | Black |
Case Material | PC-ABS (Top), PC-ABS (Bottom) |
SOFTWARE |
Operating System | WindowsĀ® 11 Pro, English |
Bundled Software | None |
CONNECTIVITY |
WLAN + Bluetooth | IntelĀ® Wi-FiĀ® 6E AX211, 802.11ax 2x2 + BT5.3 |
WWAN | Non-WWAN |
SIM Card | None |
Ethernet | 100/1000M (RJ-45) |
NFC | None |
Standard Ports | 1x USB-A (Hi-Speed USB / USB 2.0) 1x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On 1x USB-CĀ® (USB 20Gbps / USB 3.2 Gen 2x2), with USB PD 3.0 and DisplayPortā¢ 1.4 1x USB-CĀ® (Thunderboltā¢ 4 / USB4Ā® 40Gbps), with USB PD 3.0 and DisplayPortā¢ 2.1 1x HDMIĀ® 2.1, up to 4K/60Hz 1x Headphone / microphone combo jack (3.5mm) 1x Ethernet (RJ-45) |
Optional Ports (configured) | None |
Docking | Various docking solutions supported via Thunderboltā¢ or USB-CĀ®. For more compatible docking solutions, please visit Docking for ThinkPadĀ® L16 Gen 1 (IntelĀ®) |
SECURITY & PRIVACY |
Security Chip | Discrete TPM 2.0 Enabled |
Physical Locks | KensingtonĀ® Nano Security Slot, 2.5 x 6 mm |
Smart Card Reader | None |
Fingerprint Reader | Touch Style, Match-on-Chip, Integrated in Power Button |
Other Security | Camera privacy shutter IR camera for WindowsĀ® Hello (facial recognition) ThinkShield |
MANAGEABILITY |
System Management | Non-vProĀ® |
ACCESSORIES |
Bundled Accessories | None |
CERTIFICATIONS |
Green Certifications | ENERGY STARĀ® 9.0 EPEATā¢ Gold Registered ErP Lot 6/26 RoHS compliant TCO Certified 10.0 |
Mil-Spec Test | MIL-STD-810H military test passed |
