PERFORMANCE |
Processor | IntelĀ® Core Ultra 5 225H, 14C (4P + 8E + 2LPE) / 14T, Max Turbo up to 4.9GHz, 18MB |
AI PC Category | AI PC |
NPU | Integrated IntelĀ® AI Boost, up to 13 TOPS |
Graphics | Integrated IntelĀ® Arcā¢ 130T GPU |
Chipset | IntelĀ® SoC Platform |
Memory | 2x 16GB SODIMM DDR5-5600 |
Memory Slots | Models with U or H series processor: two DDR5 SODIMM / CSODIMM slots, dual-channel capable |
Max Memory | Models with U or H series processor: up to 64GB DDR5-5600 |
Storage | 512GB SSD M.2 2280 PCIeĀ® 4.0x4 NVMeĀ® Opal 2.0 |
Storage Slot | Models with V or H series processor: one M.2 2280 PCIeĀ® 5.0 x4 slot |
Max Storage Support | One drive, up to 2TB M.2 2280 SSD |
Card Reader | None |
Audio Chip | High Definition (HD) Audio, RealtekĀ® ALC3287 codec |
Speakers | Stereo speakers, 2W x2, Dolby Audioā¢ |
Microphone | 2x, 360Ā° |
Camera | 5.0MP + IR Discrete with Privacy Shutter |
Battery | 52.5Wh |
Power Adapter | 65W USB-CĀ® (3-pin) |
DESIGN |
Display | 14" WUXGA (1920x1200) IPS 400nits Anti-glare, 45% NTSC, 60Hz, DBEF5 |
Touchscreen | None |
Screen-to-Body Ratio | 85.73% |
Pen | Pen Not Supported |
Keyboard | Backlit, English |
Dimensions (WxDxH) | 315.9 x 223.7 x 10.9/16.13 (front/rear), 21.8 (maximum) mm; 12.44 x 8.81 x 0.43/0.64 (front/rear), 0.86 (maximum) inches |
Weight | Starting at 1.46 kg (3.22 lbs) |
Case Color | Black |
Case Material | PC + 20% CF (Top), PC + 20% CF (Bottom) |
SOFTWARE |
Operating System | WindowsĀ® 11 Pro, English (US) / English (UK) |
Bundled Software | LenovoĀ® AI Now |
CONNECTIVITY |
WLAN + Bluetooth | IntelĀ® Wi-FiĀ® 7 BE201, 802.11be 2x2 + BT5.4 |
WWAN | Non-WWAN |
SIM Card | None |
Ethernet | 100/1000M (RJ-45) |
NFC | None |
Standard Ports | 1x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On 2x USB-CĀ® (Thunderboltā¢ 4 / USB4Ā® 40Gbps), with USB PD 3.0 and DisplayPortā¢ 2.1 1x HDMIĀ® 2.1, up to 4K/60Hz 1x Headphone / microphone combo jack (3.5mm) 1x Ethernet (RJ-45) |
Optional Ports (configured) | None |
Docking | Various docking solutions supported via Thunderboltā¢ / USB-CĀ®. For more compatible docking solutions, please visit Docking for ThinkPad T14 Gen 6 (Intel) |
SECURITY & PRIVACY |
Security Chip | Discrete TPM 2.0 Enabled |
Physical Locks | KensingtonĀ® Nano Security Slot, 2.5 x 6 mm |
Smart Card Reader | None |
Fingerprint Reader | Touch Style, Match-on-Chip, Integrated in Power Button |
Other Security | Camera privacy shutter (camera models) IR camera for WindowsĀ® Hello (facial recognition) |
MANAGEABILITY |
System Management | Non-vProĀ® |
ACCESSORIES |
Bundled Accessories | None |
CERTIFICATIONS |
Green Certifications | ENERGY STARĀ® 9.0 EPEATā¢ Gold Registered ErP Lot 6/26 RoHS compliant TCO Certified 10.0 |
Mil-Spec Test | MIL-STD-810H military test passed |
