PERFORMANCE |
Display Size | 23.8" |
View Area | 526.8x296.3 mm |
Panel | In-Plane Switching |
Backlight | WLED |
Aspect Ratio | 16:9 |
Resolution | 2560x1440 |
Pixel Pitch | 0.205x0.205 mm |
Dot / Pixel Per Inch | 123 dpi |
View Angle (H / V) | 178° / 178° |
Response Time | 4ms (Extreme mode) / 6ms (Typical mode) |
Color Support | 16.7 Million |
Refresh Rate | 60Hz |
Brightness | 300 cd/m² |
Contrast Ratio | 1000:1 |
Color Gamut | 99% sRGB, 99% BT.709 |
Screen Surface Treatment | Anti-glare |
Curvature | None |
Camera | Modular Camera Support |
Microphone | None |
Speakers | Modular Speaker Support |
Power Consumption (Typical / Maximum) | 27W / 161W |
Power Adapter | Integrated |
Touchscreen | None |
Smart System | None |
DESIGN |
Stand | Tilt, Swivel, Pivot, Height Adjust Stand |
Case Color | Raven Black |
Side Bezel Width | 2 mm |
Mounting | Supports VESA mount 100mm |
ThinkCentre M Series Support | Tiny Support |
Pen | None |
Dimensions (WxDxH) | Lowest Position | 539.5 x 199.7 x 348.8mm (21.24 x 7.86 x 13.73 inches) Highest Position | 539.5 x 199.7 x 503.8mm (21.24 x 7.86 x 19.83 inches) Head Only | 539.5 x 46.5 x 323.7mm (21.24 x 1.83 x 12.74 inches) |
Packaging Dimensions (WxDxH) | 620 x 160 x 420 mm (24.41 x 6.30 x 16.54 inches) |
Weight | Monitor With Stand | 5.7 kg (12.6 lbs) Monitor Head Only | 3.8 kg (8.4 lbs) |
Packaging Weight | 8.6 kg (19.00 lbs) |
CONNECTIVITY |
USB Port | 4x USB 3.2 Gen 1 (1x BC 1.2), 1x USB-C® 3.2 Gen 1 (DP 1.4 Alt Mode, up to 100W PD, USB upstream) |
Video Connector | 1x HDMI® 2.1 TMDS, 1x DP 1.4, 1x DP Out, 1x USB-C® 3.2 Gen 1 (DP 1.4 Alt Mode) |
Network Connectivity | 1x RJ45, Ethernet (10M/100M/1000M) |
CERTIFICATIONS |
Environmental Certification | ENERGY STAR® Certified, TCO 9.0, TCO Edge 2.0, EPEAT™ Gold, RoHS |
Ergonomic Certification | Eyesafe® Display 2.0, TÜV Low Blue Light (Hardware solution), TÜV Rheinland® Low Blue Light, TÜV Rheinland Flicker Free, TÜV Rheinland Eye Comfort |
Sync Technology | None |
Special Features | HDR10 Compliance Factory Calibration: Avg. Delta E<2 Lenovo® ThinkColour (Lenovo Accessories and Display Manager) Support Lenovo ThinkColour supports Windows® 10 & 11, Mac OS, and Windows On Arm (functions vary across systems). Lenovo Accessories and Display Manager is formerly Lenovo Display Control Center. Natural Low Blue Light Smart Power The Smart Power function intelligently detects overall power consumption and dynamically manages the power delivery to each device |
SOFTWARE |
Operating System | Support Windows® 10, Windows 11 |
ACCESSORIES |
Video Cables | USB Type-C® to Type-C Cable |
