PERFORMANCE |
Display Size | 23.8“ |
View Area | 526.8x296.4 mm |
Panel | In-Plane Switching |
Backlight | WLED |
Aspect Ratio | 16:9 |
Resolution | 2560x1440 |
Pixel Pitch | 0.2058x0.2058 mm |
Dot / Pixel Per Inch | 123 dpi |
View Angle (H / V) | 178° / 178° |
Response Time | 4ms GtG (Extreme mode) / 6ms GtG (Typical mode) |
Color Support | 16.7 Million |
Refresh Rate | 48Hz - 120Hz |
Brightness | 300 cd/m² |
Contrast Ratio | 1500:1 |
Color Gamut | 99% sRGB, 99% BT.709 |
Screen Surface Treatment | Anti-glare |
Curvature | Flat Panel |
Camera | Modular Camera Support |
Microphone | None |
Speakers | Modular Speaker Support |
Power Consumption (Typical / Maximum) | 16.5W / 210W |
Power Adapter | Integrated |
DESIGN |
Stand | Tilt, Swivel, Pivot, Height Adjust Stand |
Case Color | Eclipse Black |
Side Bezel Width | 2 mm |
Mounting | Supports VESA mount 100 x 100 mm |
ThinkCentre M Series Support | Tiny Support |
Dimensions (WxDxH) | Lowest Position | 539.8 x 190.0 x 350.8 mm (21.25 x 7.48 x 13.81 inches) Highest Position | 539.8 x 190.0 x 505.8 mm (21.25 x 7.48 x 19.91 inches) Head Only | 539.8 x 45.3 x 315.8 mm (21.25 x 1.78 x 12.43 inches) |
Packaging Dimensions (WxDxH) | 730 x 123 x 420 mm (28.74 x 4.84 x 16.54 inches) |
Weight | Monitor With Stand | 5.6 kg (12.4 lbs) Monitor Head Only | 3.6 kg (8.0 lbs) |
Packaging Weight | 8.4 kg (18.4 lbs) |
CONNECTIVITY |
USB Port | x USB-C® (USB 10Gbps,DP 1.4 Alt Mode HBR3, PD3.1 140W, USB upstream), 1x USB-B (USB 5Gbps, USB upstream), 4x USB-A (USB 5Gbps, 1x BC1.2, USB downstream), 1x USB-C® (USB 5Gbps, 15WPD, USB downstream) |
Video Connector | 1x HDMI® 2.1 TMDS, 1x DP 1.4 (HBR3), 1x DP 1.4 Out, 1x USB-C® (10Gbps, DP 1.4 Alt Mode HBR3) |
Network Connectivity | 1x RJ45, Ethernet (10M/100M/1000M/2500M) |
CERTIFICATIONS |
Environmental Certification | ENERGY STAR® Certified, TCO 10, TCO Edge 2.1, EU Energy Efficiency Level (Level-D), EPEAT™ Gold, Volatile Organic Compound Certification, RoHS |
Ergonomic Certification | TÜV Rheinland® Eye Comfort 5 Stars, Eyesafe® Display 2.0, TÜV Low Blue Light (Hardware solution) |
Sync Technology | None |
Special Features | HDR10 Compliance Factory Calibration: Avg. Delta E<2 at sRGB Lenovo® ThinkColour (Lenovo® Accessories and Display Manager) Support Lenovo® ThinkColour supports Windows® 10 & 11, Mac OS (functions vary across systems). Lenovo® Accessories and Display Manager is formerly Lenovo® Display Control Center. KVM Switch (with eKVM) LDFM (Lenovo® Display Fleet Manager) Mirrored Power Button Multi-sync Natural Low Blue Light Smart Power |
SOFTWARE |
Operating System | Support Windows® 10, Windows® 11 |
ACCESSORIES |
In the Box | Monitor with stand 1x DP 1.4 cable (1.8m) 1x USB-C® to USB-C® Gen 2 cable (1.5m) 1x USB-B to USB-A Gen 1 cable (1.8m) 1x Power cable (1.8m) Factory calibration report Quick setup guide |
