Noctua 120mm PWM Fan - Chromax Black (NF-A12X25-PWM-CH-BK-S)

Noctua 120mm PWM Fan - Chromax Black (NF-A12X25-PWM-CH-BK-S)
  • 120mm-Case-Fans-Noctua-NF-A12x25-120mm-PWM-Fan-Chromax-Black-5
  • 120mm-Case-Fans-Noctua-NF-A12x25-120mm-PWM-Fan-Chromax-Black-3
  • 120mm-Case-Fans-Noctua-NF-A12x25-120mm-PWM-Fan-Chromax-Black-2
$69.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Click & Collect   Question Mark

Your store is set to:

Loading... Contact Store

   Monday Dispatch   Question Mark

Order within 15hrs and 45mins

Question Mark

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    Noctua 120mm PWM Fan - Chromax Black (NF-A12X25-PWM-CH-BK-S)
  • Model Number:
    NF-A12X25-PWM-CH-BK-S
  • Brand:
  • Manufacturer Warranty:
    6 Year

Description

120mm-Case-Fans-Noctua-NF-A12x25-120mm-PWM-Fan-Chromax-Black-1





SPECIFICATIONS:

Size

120x120x25 mm

Mounting hole spacing

105x105 mm

Connector &   pin-configuration

4-pin PWM

Cable length

2cm + 30cm NA-EC1 extension cable

Bearing

SSO2

Blade geometry

A-Series with Flow Acceleration Channels

Frame technology

AAO (Advanced Acoustic Optimisation)

Material

Sterrox® LCP

Rotational speed (+/- 10%)

2000 RPM

Min. rotational speed @ 20% PWM (+/-20%)

450 RPM

Airflow

102,1 m/h

Acoustical noise

22,6 dB(A)

Static pressure

2,34 mm H₂O

Input power (typical)

1,2 W

Input power (max.)

1,68 W

Input current (typical)

0,1 A

Max. input current

0,14 A

Operating voltage

12 V

Voltage PWM signal

5 V

MTTF

> 150.000 h

Scope of delivery

4x NA-AVP1 chromax.black anti-vibration pads

4x NA-AVP1 chromax.blue anti-vibration pads

4x NA-AVP1 chromax.green anti-vibration pads

4x NA-AVP1 chromax.red anti-vibration pads

4x NA-AVP1 chromax.white anti-vibration pads

4x NA-AVP1 chromax.yellow anti-vibration pads

4x NA-AVP1 grey anti-vibration pads

NA-AVG1 chromax.black anti-vibration gasket for water cooling radiators

Fan screws
