SPECIFICATIONS:
Size
40x40x10 mm
Mounting hole spacing
32x32 mm
Connector & pin-configuration
4-pin PWM
Cable length
20cm + 30cm NA-EC1 extension cable
Bearing
SSO2
Blade geometry
A-Series with Flow Acceleration Channels
Frame technology
AAO (Advanced Acoustic Optimisation)
Material
Fibre-glass reinforced PBT
Rotational speed (+/- 10%)
5000 RPM
Airflow
8,9 m/h
Acoustical noise
19,6 dB(A)
Static pressure
1,95 mm Hâ‚‚O
Input power (max.)
1,08 W
Max. input current
0,045 A
Operating voltage
24 V
MTTF
> 150.000 h
Scope of delivery
NA-AC9 4-pin molex to 2-pin adaptor cable
OmniJoinâ„¢ adaptor set
NA-EC1 30cm extension cable
NA-RC8 Low-Noise Adaptor (L.N.A)
4x NA-AV3 anti-vibration mounts
Fan screws
Notes and warnings
Caution: Being a 24V fan, the NF-A4x10 24V cannot be run at 12V and requires a starting voltage of at least 17V. It is therefore not suitable for standard PC applications.
