Height (with feet)

400 mm (15.75 in)

Width

225 mm (8.86 in)

Depth

389 mm (15.31 in)

Volume

35.0 L

Weight

4.8 kg (10.58 lb)

GENERAL

Enclosure Type

Micro-ATX Case

Motherboard Compatibility

Micro-ATX, Mini-ITX

Supports Rear-Connecting Motherboard
(BTF, Project Zero)

Yes (Micro-ATX)

Materials

SGCC steel, clear tempered glass

CLEARANCE

CPU Cooler Height

170 mm

GPU Length

Up to 377 mm (without front fans) Up to 352 mm (with front fans) Up to 317 mm (with front radiator and fans)

PSU Length

Up to 185 mm

Cable Routing Space

Up to 31.5 mm

Front Radiator + Fan Thickness

Up to 63 mm

Top Radiator + Fan Thickness

Up to 70 mm

FRONT I/O PORTS

USB 3.2 Type-A

1

USB 3.2 Gen2x2 Type-C

1

EXPANSION SLOTS

Standard

4

Vertical

0

DRIVE BAYS

2.5"

1+2

3.5"

1

FAN SUPPORT

Front

2 x 120 mm / 2 x 140 mm

Top

2 x 120 mm / 2 x 140 mm

Bottom

2 x 120 mm

Rear

1 x 120 mm (1 x F120Q (CV) included)

RADIATOR SUPPORT

Front

Up to 280 mm

Top

Up to 240 mm

FAN SPECS

Model

F120Q (CV)

Speed

1,350 ± 150 RPM

Airflow

60.2 CFM

Static Pressure

1.05 mmH2O

Noise

24.1 dBA

Fan Connector

3-pin
