Motherboard Support

E-ATX (Up to 277 mm wide), ATX, Micro-ATX, Mini-ITX

Enclosure Type

Mid-Tower

Case Material

SGCC Steel, Ultra-Clear Tempered Glass (White), Dark Tinted Tempered Glass (Black)

DIMENSIONS

Height (with feet)

465 mm / 18.31 in

Width

225 mm / 8.86 in

Depth

430 mm / 16.93 in

Weight

7.63 kg / 16.82 lb

COMPATIBILITY & CLEARANCE

CPU Cooler Height

Up to 170 mm

GPU Length

Up   to 410 mm

PSU Length

Up to 200 mm

Cable Management

Up   to 28.7 mm

Top Radiator

Up to 240 mm (280 mm with low-profile memory)

Top Mounted Radiator + Fan Thickness

Up   to 55 mm

FRONT PORTS

USB 3.2 Type-A

1

USB 3.2 Gen 2x2 Type-C (20 Gbps)

1

Headset Audio Jack

1

EXPANSION SLOTS

Standard

7

Vertical

0

DRIVE BAYS

2.5"

2

3.5"

1

FAN SUPPORT

Front

3 x 120 mm / 2 x 140 mm (1 x F360 RGB Core Case Version included)

Top

2 x 120 mm / 2 x 140 mm

Bottom

2 x 120 mm

Rear

1 x 120 mm (1 x F120Q Case Version included)

RADIATOR SUPPORT

Front

Up to 360 mm

Top

Up to 240 mm (280 mm with low-profile memory only)

FAN SPECS - F360 RGB CORE (CASE VERSION)

Model

F360 RGB Core (Case Version)

Speed

1,700 ± 200 RPM

Airflow

50.1 CFM

Static

1.27 mm-H₂O

Noise

23.3 dBA

Fan Connector

3-pin DC

FAN SPECS - F120Q (CASE VERSION)

Model

F120Q (Case Version)

Speed

1,350 ± 150 RPM

Airflow

60.2 CFM

Static

1.05 mm-H₂O

Noise

24.1 dBA

Fan Connector

3-pin DC

OTHERS

Inside the Box

H5 Flow RGB

F360 RGB Core (CV)

F120Q (CV)

Installation accessories

User guide
