PICTURE/DISPLAY |
|
Panel Size | 23.8 inch/60.47 cm |
Aspect ratio | 16:9 |
LCD panel type | IPS technology |
Backlight type | W-LED system |
Pixel pitch | 0.2745(H)mm x 0.2745(V)mm |
Brightness | 300cd/m² |
Display colors | 16.7M (8 bit) |
Color gamut (typical) | sRGB 110% , NTSC 96% * |
Contrast ratio (typical) | 1500:1 |
SmartContrast | 50,000,000:1 |
Response time (typical) | 4 ms (Gray to Gray)* |
Viewing angle | 178º (H) / 178º (V) @ C/R > 10 |
Picture enhancement | SmartImage |
Maximum resolution | 1920x1080@120Hz |
Effective viewing area | 527.04(H)x296.46(V) mm |
Scanning Frequency | 30k-140 kHz (H) / 48-120 Hz (V) |
sRGB | Yes |
SoftBlue | Yes |
Flicker-free | Yes |
Pixel Density | 93 PPI |
Display Screen Coating | Anti-Glare, 3H, Haze 25% |
EasyRead | Yes |
Adaptive sync | Yes |
EyeSafe | Yes |
Smart Link Sync | When used as a primary or secondary monitor* |
CONNECTIVITY |
|
Signal Input | HDMI 1.4 x 1, DisplayPort 1.4 x 1, USB-C x 1 (upstream, DP Alt mode, Data, PD) |
Sync Input | Separate Sync Sync on Green |
Audio (In/Out) | Audio out |
RJ45 | Ethernet LAN (USB 2.0: 10M/100M; USB 3.0: 1000M) |
Signal Output | DP out |
HDCP | HDCP 1.4 (HDMI / DisplayPort ) |
USB Hub | USB3.2, Gen1, 5G, upstream: 1x USB-C (Full) ,downstream: USB-A x4 (with x1 fast charge B.C 1.2) |
POWER DELIVERY |
|
Max power delivery | Up to 90W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.5A) |
Version | USB PD version 3.0 |
CONVENIENCE |
|
Built-in Speakers | 2W x 2 |
Plug & Play Compatibility | DDC/CI Mac OS sRGB Windows 11 / 10 |
User convenience | SmartImage Input Brightness Menu Power On/Off |
OSD Languages | Brazil Portuguese Czech Dutch English French Finnish German Greek Hungarian Italian Japanese Korean Portuguese Polish Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish Ukrainian |
Other convenience | Kensington lock VESA mount (100x100mm) |
Control software | SmartControl Stand |
Height adjustment | 150 mm |
Pivot | -/+90 degree |
Swivel | -/+180 degree |
Tilt | -5/30 degree |
POWER |
|
ECO mode | 10.4 W (typ.) |
Power supply | Built-in 100-240VAC, 50-60Hz |
Off mode | 0.3 W (typ) |
On mode | 13.53 W (typ.) (EnergyStar test method) |
Standby mode | 0.3 W (typ) |
Power LED indicator | Operation - White Standby mode- White (blinking) |
Energy Label Class | C |
DIMENSIONS |
|
Packaging in mm (WxHxD) | 690 x 395 x 124 mm |
Product without stand (mm) | 542 x 320 x 48 mm |
Product with stand (max height) | 542 x 499 x 228 mm |
WEIGHT |
|
Product with packaging (kg) | 7.75 kg |
Product with stand (kg) | 5.72 kg |
Product without stand (kg) | 3.70 kg |
OPERATING CONDITIONS |
|
Altitude | Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
Temperature range (operation) | 0°C to 40 °C |
Relative humidity | 20%-80 % |
Temperature range (storage) | -20°C to 60 °C |
MTBF (demonstrated) | 70,000 hrs (excluded backlight) |
SUSTAINABILITY |
|
Environmental and energy | Energy Star EPEAT* RoHS |
Post consumer recycled plastic | 85% |
Recyclable packaging material | 100% |
Specific Substances | PVC / BFR free housing |
COMPLIANCE AND STANDARDS |
|
Regulatory Approvals | ETL CEC CB TUV/GS TUV Ergo TCO Certified TCO Certified Edge EAC EAEU RoHS MEPS CE Mark UKCA EMF FCC ICES-003 TÜV Rheinland Low Blue Light (Hardware Solution) eyesafe® CERTIFIED 2.0 |
CABINET |
|
Finish | Texture |
Foot | Black |
Front bezel | Black |
Rear cover | Black |
WHAT'S IN THE BOX |
|
Cables | HDMI cable, DisplayPort cable, USB-C to C cable, Power cable |
Monitor with stand | Yes |
User Documentation | Yes |
