PICTURE/DISPLAY |
|
Panel Size | 23.8 inch / 60.5 cm |
Aspect ratio | 16:9 |
LCD panel type | IPS technology |
Backlight type | W-LED system |
Pixel pitch | 0.2745 x 0.2745 mm |
Brightness | 300cd/m² |
Display colors | 16.7 M (8 bit) |
Color gamut (typical) | NTSC 88%*, sRGB 105%* |
Contrast ratio (typical) | 1000:1 |
SmartContrast | 50,000,000:1 |
Response time (typical) | 4 ms (Gray to Gray)* |
Viewing angle | 178º (H) / 178º (V) @ C/R > 10 |
Picture enhancement | SmartImage |
Maximum resolution | 1920 x 1080 @ 75 Hz |
Effective viewing area | 527.04 (H) x 296.46 (V) |
Scanning Frequency | 30 - 85 kHz (H) / 48 - 75 Hz (V) |
sRGB | Yes |
Flicker-free | Yes |
Pixel Density | 93 PPI |
LowBlue Mode | Yes |
Display Screen Coating | Anti-Glare, 3H, Haze 25% |
EasyRead | Yes |
CONNECTIVITY |
|
Signal Input | HDMI 1.4 x 1, DisplayPort 1.4 x 1, USB-C x 1 (upstream, DP Alt mode, Data, PD up to 90W) |
Sync Input | Separate Sync |
Audio (In/Out) | Audio out / Microphone in combo jack |
RJ45 | Ethernet LAN up to 1G*, Wake on LAN |
Signal Output | DisplayPort out x 1 |
HDCP | HDCP 1.4 (HDMI / DisplayPort / USB-C); HDCP 2.2 (HDMI / DisplayPort / USB-C) |
HBR3 | HBR 3 (DisplayPort, USB-C) |
USB Hub | USB 3.2, Gen 2 / 10 Gbps, USB-C upstream x 1 (Data), USB-A downstream x 4 (with 1 for fast charge B.C 1.2), USB-C downstream x 1 (Data, PD 15W) |
POWER DELIVERY |
|
Max power delivery | USB-C up to 90W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.5A) |
Version | USB PD version 3.0 |
CONVENIENCE |
|
Built-in Speakers | 5 W x 2 |
Plug & Play Compatibility | DDC/CI Mac OS X sRGB Windows 11 / 10 / 8.1 / 8 / 7 |
User convenience | SmartImage Input User Menu Power On/Off |
OSD Languages | Brazil Portuguese Czech Dutch English French Finnish German Greek Hungarian Italian Japanese Korean Portuguese Polish Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish Ukrainian |
Other convenience | Kensington lock VESA mount (100x100mm) |
Control software | SmartControl |
MultiView | PIP/PBP mode 2x devices |
Built-in webcam | Pop-up 5.0 megapixel camera with microphone and LED indicator (for Windows Hello) |
KVM | Yes (USB-C/USB-C) |
Noise cancellation | Yes |
STAND |
|
Height adjustment | 150 mm |
Pivot | -/+90 degree |
Swivel | -/+180 degree |
Tilt | -5/30 degree |
POWER |
|
Power supply | Built-in 100-240VAC, 50-60Hz |
Off mode | Zero watts with AC switch |
On mode | 15.3 W (typ.) (EnergyStar test method) |
Standby mode | 0.3 W (typ.) |
Power LED indicator | Operation - White Standby mode- White (blinking) |
DIMENSIONS |
|
Packaging in mm (WxHxD) | 600 x 406 x 198 mm |
Product without stand (mm) | 540 x 323 x 51 mm |
Product with stand (max height) | 540 x 500 x 205 mm |
WEIGHT |
|
Product with packaging (kg) | 8.32 kg |
Product with stand (kg) | 5.50 kg |
Product without stand (kg) | 3.90 kg |
OPERATING CONDITIONS |
|
Altitude | Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
Temperature range (operation) | 0°C to 40* °C |
Relative humidity | 20%-80 % |
Temperature range (storage) | -20°C to 60 °C |
MTBF (demonstrated) | 70,000 hrs (excluded backlight) |
SUSTAINABILITY |
|
Environmental and energy | PowerSensor LightSensor EnergyStar 8.0 EPEAT* TCO Certified Edge RoHS |
Post consumer recycled plastic | 85% |
Recyclable packaging material | 100 % |
Specific Substances | Mercury free PVC / BFR free housing |
COMPLIANCE AND STANDARDS |
|
Regulatory Approvals | CB CE Mark FCC Class B ICES-003 CU-EAC EAEU RoHS TUV Ergo TUV/GS TUV Eye Comfort certified cETLus MEPS RCM |
