Panel Size

23.8 inch / 60.5 cm

Aspect ratio

16:9

LCD panel type

IPS technology

Backlight type

W-LED system

Pixel pitch

0.2745 x 0.2745 mm

Brightness

300 cd/m²

Display colors

16.7 M

Color gamut (typical)

Adobe RGB 84.49%; DCI-P3:81.39%, sRGB: 102.66%, NTSC 89.36%*

Contrast ratio (typical)

1500:1

SmartContrast

Mega Infinity DCR

Response time (typical)

4 ms (Gray to Gray)*

Viewing angle

178º (H) / 178º (V)

@ C/R > 10

Picture enhancement

SmartImage

Maximum resolution

1920x1080 @ 120 Hz

Effective viewing area

527.04 (H) x 296.46 (V) mm

Scanning Frequency

30 KHz - 140 KHz (H) / 48 Hz - 120 Hz (V)

sRGB

Yes

SoftBlue

Yes

Flicker-free

Yes

Pixel Density

93 PPI

LowBlue Mode

Yes

Display Screen Coating

Anti-Glare, 3H, Haze 25%

MPRT

1   ms*

EasyRead

Yes

Adaptive sync

Yes

CONNECTIVITY

Signal Input

HDMI 1.4 x 1, USB-C x 1 (DisplayPort Alt mode)

Sync Input

Separate Sync

Audio (In/Out)

Audio out

HDCP

HDCP 1.4 (HDMI / USB-C)

USB Hub

USB 3.2 Gen 1, USB-A downstream x 2 (with 1 fast charge B.C 1.2)

POWER DELIVERY

Max power delivery

USB-C: Up to 65W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A)

Version

USB PD version 3.0

CONVENIENCE

Built-in Speakers

2W X 2

Plug & Play   Compatibility

DDC/CI

Mac   OS X

sRGB

Windows   11 / 10

User convenience

Power On/Off

Menu

Volume

Input

SmartImage

OSD Languages

Brazil   Portuguese

Czech

Dutch

English

Finnish

French

German

Greek

Hungarian

Italian

Japanese

Korean

Polish

Portuguese

Russian

Simplified Chinese

Spanish

Swedish

Traditional Chinese

Turkish

Ukrainian

Other convenience

Kensington lock

VESA mount (100x100mm)

STAND

Tilt

-5/20 degree

POWER

Power supply

Internal

100-240VAC, 50-60Hz

Off mode

0.3   W (typ.)

On mode

18.3 W (typ.)

Standby mode

0.5   W (typ.)

Power LED indicator

Operation - White

Standby mode- White (blinking)

DIMENSIONS

Packaging in mm (WxHxD)

610 x 370 x 124 mm

Product without stand (mm)

542x316x45 mm

Product with stand (max height)

542x417x180 mm

WEIGHT

Product with packaging (kg)

5.26  kg

Product with stand (kg)

3.41  kg

Product without stand (kg)

3.06  kg

OPERATING CONDITIONS

Altitude

Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

Temperature range (operation)

0   to 40  °C

MTBF

50,000 hrs (excluding backlight) hour(s)

Relative humidity

20%-80  %

Temperature range (storage)

-20 to 60  °C

SUSTAINABILITY

Environmental and energy

RoHS

Recyclable packaging material

100  %

Specific Substances

PVC / BFR free housing

COMPLIANCE AND STANDARDS

Regulatory Approvals

CB

CE Mark

MEPS

UKCA

EMF

FCC

ICES-003
