Picture/Display |
|
LCD panel type | VA LCD |
Backlight type | W-LED system |
Panel Size | 48.8 inch / 124 cm |
Display Screen Coating | Anti-Glare, 3H, Haze 25% |
Effective viewing area | 1191.936 (H) x 335.232 (V) mm at a 1800R curvature* |
Aspect ratio | 32:9 |
Maximum resolution | HDMI: 5120 x 1440 @ 75 Hz; DP: 5120 x 1440 @ 165 Hz* |
Pixel Density | 109 PPI |
Response time (typical) | 4 ms (Gray to Gray)* |
Brightness | 550 cd/m² |
Contrast ratio (typical) | 3000:1 |
SmartContrast | 80,000,000:1 |
Pixel pitch | 0.233 x 0.233 mm |
Viewing angle | 178º (H) / 178º (V)@ C/R > 10 |
Flicker-free | Yes |
Picture enhancement | SmartImage |
Display colors | 16.7 M |
Color gamut (min.) | DCI-P3 91%* |
Color gamut (typical) | NTSC 100%*, sRGB 122%*, Adobe RGB 89%* |
HDR | DisplayHDR 400 certified |
Scanning Frequency | HDMI: 30 - 200 kHz (H) / 48 - 120 Hz (V); DP: 30 - 250 kHz (H) / 48 - 165 Hz (V) |
SmartUniformity | 93 ~ 105% |
Delta E | < 2 |
sRGB | Yes |
LowBlue Mode | Yes |
EasyRead | Yes |
Adaptive sync | Yes |
Connectivity |
|
Signal Input | DisplayPort 1.4 x 1, HDMI 2.0 x 3 |
HDCP | HDCP 2.2 (HDMI / DP) |
USB: | USB 3.2 x 2 (upstream), USB 3.2 x 4 (downstream with x 1 fast charge B.C 1.2) |
Sync Input | Separate Sync |
Audio (In/Out) | Audio out |
Convenience |
|
Built-in Speakers | 5 W x 2 |
MultiView | PBP (2x devices) |
KVM | Yes |
User convenience | SmartImage Input User Menu Power On/Off |
Control software | SmartControl |
OSD Languages | Brazil Portuguese Czech Dutch English Finnish French German Greek Hungarian Italian Japanese Korean Polish Portuguese Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish Ukranian |
Other convenience | Kensington lock VESA mount (100x100mm) Plug & Play Compatibility DDC/CI Mac OS X sRGB Windows 10 / 8.1 / 8 / 7 |
Stand |
|
Height adjustment | 130 mm |
Swivel | -/+ 20 degree |
Tilt | -5~15 degree |
Power |
|
ECO mode | 46.2 W (typ.) |
On mode | 51.4 W (typ.) (EnergyStar test method) |
Standby mode | 0.4 W (typ.) |
Off mode | Zero watts with Zero switch |
Power LED indicator | Operation - White |
Standby mode- White (blinking) | Power supply |
Built-in | 100-240VAC, 50-60Hz |
Dimensions |
|
Product with stand(max height) | 1194 x 568 x 303 mm |
Product without stand (mm) | 1194 x 369 x 156 mm |
Packaging in mm (WxHxD) | 1308 x 384 x 553 mm |
Weight |
|
Product with stand (kg) | 15.20 kg |
Product without stand (kg) | 10.90 kg |
Product with packaging (kg) | 21.50 kg |
Operating conditions |
|
Temperature range (operation) | 0°C to 40°C °C |
Temperature range (storage) | -20°C to 60°C °C |
Relative humidity | 20%-80 % |
Altitude | Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
MTBF (demonstrated) | 70,000 hrs (excluded backlight) |
Sustainability |
|
Environmental and energy | EnergyStar 8.0 EPEAT* TCO Certified RoHS |
Recyclable packaging material | 100 % |
|
Post consumer recycled plastic | 35% |
|
Specific Substances | PVC / BFR free housing Mercury free |
|
Compliance and standards |
|
|
Regulatory Approvals | cETLus CB TUV/GS TUV Ergo SEMKO CU-EAC EAEU RoHS RCM MEPS CEL CE Mark FCC Class B ICES-003 |
|
Cabinet |
|
|
Front bezel | Black |
|
Rear cover | Black |
|
Foot | Black |
|
Finish | Texture |
|
