Panel Size

23.8"/60.5 cm

Aspect ratio

16:9

LCD panel type

IPS technology

Backlight type

W-LED system

Pixel pitch

0.2745 x 0.2745mm

Brightness

300 cd/m²

Display colors

16.7 M

Color gamut (typical)

Adobe RGB 89%; DCI-P3:93% sRGB: 125%,, NTSC 105%.*

Contrast ratio (typical)

1000:1

SmartContrast

Mega Infinity DCR

Response time (typical)

1 ms (Gray to Gray)*

Viewing angle

178º (H) / 178º (V)

@ C/R > 10

Picture enhancement

SmartImage game

Maximum resolution

1920x1080 @ 200Hz (HDMI/DP)*

Effective viewing area

527.04(H)x296.46(V)mm

Scanning Frequency

30-230 KHz(H)/ 48-200 Hz(V)

sRGB

Yes

Flicker-free

Yes

Pixel Density

93   PPI

LowBlue Mode

Yes

Display Screen Coating

Anti-Glare, 3H, Haze 25%

Low Input Lag

Yes

Adaptive sync

Yes

HDR

HDR 10 supported

Stark Shadow Boost

Yes

Smart MBR

0.3ms*

Smart Crosshair

Yes

Shadow Boost

Yes

CONNECTIVITY

Signal Input

HDMI 2.0 x 1, DisplayPort 1.4 x 1

Sync Input

Separate Sync

Audio (In/Out)

Headphone out

HDCP

HDCP 1.4 (HDMI / DP), HDCP 2.2 (HDMI / DP)

CONVENIENCE

Plug & Play Compatibility

DDC/CI

Mac   OS

sRGB

Windows 11 / 10

User convenience

Power On/Off

Menu/OK

Input/Up

Game Settings/Down

SmartImage game/Back

OSD Languages

Brazil Portuguese

Czech

Dutch

English

Finnish

French

German

Greek

Hungarian

Italian

Japanese

Korean

Polish

Portuguese

Russian

Spanish

Simplified Chinese

Swedish

Turkish

Traditional Chinese

Ukrainian

Other convenience

Kensington lock

VESA mount (100x100mm)

LowBlue Mode

Stand

Tilt

-5/20  degree

Power

Power supply

Internal

100-240VAC, 50-60Hz

Off mode

0.3 W (typ.)

On mode

23.4 W (typ.)

Standby mode

0.5 W (typ.)

Power LED indicator

Operation - White

Standby mode- White (blinking)

DIMENSIONS

Packaging in mm (WxHxD)

615 x 420 x 126  mm

Product without stand (mm)

540 x 325 x 54  mm

Product with stand (max height)

540 x 433 x 216  mm

WEIGHT

Product with packaging (kg)

5.49  kg

Product with stand (kg)

3.21  kg

Product without stand (kg)

2.65  kg

OPERATING CONDITIONS

Altitude

Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

Temperature range (operation)

0°C   to 40  °C

MTBF

50,000 (Excluded backlight)  hour(s)

Relative humidity

20%-80  %

Temperature range (storage)

-20°C to 60  °C

SUSTAINABILITY

Environmental and energy

RoHS

Recyclable packaging material

100  %

Post consumer recycled plastics

85%*

COMPLIANCE AND STANDARDS

Regulatory Approvals

INMETRO

CB

CEL

CCC

CECP

CE Mark

UKCA

EMF

FCC

ICES-003
