PICTURE/DISPLAY |
|
Panel Size | 31.5"/80cm |
Aspect ratio | 16:9 |
Monitor Panel Type | QD OLED |
Pixel pitch | 0.1814 x 0.1814mm |
Brightness | SDR: 250nits (APL 100%) nit,HDR: 450 (APL 10%) nit, HDR E/P: 1000 (APL 3%) nit |
Display colors | Color support 1.07 billion colors (10 bit) |
Color gamut (typical) | DCI-P3:99%, sRGB: 147.5%, NTSC 120%, Adobe RGB 118%* |
Contrast ratio (typical) | 1,500,000:1 |
SmartContrast | Mega Infinity DCR |
Response time (typical) | 0.03 ms (Gray to Gray)* |
Viewing angle | 178º (H) / 178º (V) @ C/R > 10000 |
Picture enhancement | SmartImage game |
Maximum resolution | 3840x2160 @ 240 Hz (HDMI/DP) |
Effective viewing area | 699.48(H)x394.73(V)mm |
Scanning Frequency | 30k-510kHz(H)/ 48-240Hz(V) |
sRGB | Yes |
Delta E | <2 (sRGB) |
Flicker-free | Yes |
Pixel Density | 139.87 PPI |
LowBlue Mode | Yes |
Display Screen Coating | Anti-reflection, 2H |
Low Input Lag | Yes |
EasyRead | Yes |
Adaptive sync | Yes |
G-SYNC | Yes |
HDR | DisplayHDR True Black 400 certified |
Ambiglow | 3-sided |
Pixel format | RGB Q-Stripe* |
Clear MR Tier | 13000 |
Smart Sniper | Yes |
Stark Shadow Boost | Yes |
Windows Dynamic Lighting | Yes |
Smart Crosshair | Yes |
CONNECTIVITY |
|
Signal Input | HDMI 2.1 x 2, DisplayPort 1.4 x 1, USB-C x 1 (DP Alt mode, Video, Data) |
Sync Input | Separate Sync |
Audio (In/Out) | Audio out |
HDCP | HDCP 1.4 (HDMI / DisplayPort), HDCP 2.2 (HDMI / DisplayPort), HDCP 2.3 (HDMI / DisplayPort / ) |
USB Hub | USB 3.2 Gen1, 5 Gbps; USB UP, USB-C upstream x 1 (DP Alt mode) , USB-A downstream x 2 (with 1 for fast charge B.C 1.2) |
POWER DELIVERY |
|
Max power delivery | USB-C up to 65 W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A) |
Version | USB PD version 3.0 |
CONVENIENCE |
|
Built-in Speakers | 5 W x 2,DTS Sound |
Plug & Play Compatibility | DDC/CI Mac OS X sRGB Windows 11 / 10 |
User convenience | Power On/Off Menu/OK Input/Up Game Settings/Down SmartImage game/Back |
OSD Languages | Brazil Portuguese Czech Dutch English Finnish French German Greek Hungarian Italian Japanese Korean Polish Portuguese Russian Spanish Simplified Chinese Swedish Turkish Traditional Chinese Ukrainian |
Other convenience | Kensington lock VESA mount (100x100mm) VESA bracket |
MultiView | PIP/PBP mode 2x devices |
KVM | Yes |
Low blue light | Low blue light compliance* |
Ambiglow | Ambiglow 3 sided |
STAND |
|
Height adjustment | 130 mm |
Swivel | -/+ 30 degree |
Tilt | -5/20 degree |
POWER |
|
Power supply | Internal 100-240VAC, 50-60Hz |
Off mode | 0.3 W (typ.) |
On mode | 130.9 W (typ.) |
Standby mode | 0.5 W (typ.) |
Power LED indicator | Operation - White Standby mode- White (blinking) |
DIMENSIONS |
|
Packaging in mm (WxHxD) | 840 X 510 X 160 mm |
Product without stand (mm) | 717 X 419 X 92 mm |
Product with stand (max height) | 717 x 572 x 311 mm |
WEIGHT |
|
Product with packaging (kg) | 13.67 kg |
Product with stand (kg) | 9.65 kg |
Product without stand (kg) | 8.18kg |
OPERATING CONDITIONS |
|
Altitude | Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
Temperature range (operation) | 0°C to 40°C |
MTBF | 30,000hour(s) |
Relative humidity | 20%-80 % |
Temperature range (storage) | -20°C to 60 °C |
SUSTAINABILITY |
|
Environmental and energy | RoHS |
Recyclable packaging material | 100 % |
Specific Substances | Mercury free PVC / BFR free housing |
Post consumer recycled plastics | 35%* |
COMPLIANCE AND STANDARDS |
|
Regulatory Approvals | CB CE Mark ETL TUV/ISO9241-307 PSB EAC EAEU RoHS TUV-BAUART BSMI UKCA EMF FCC ICES-003 |
