SPECIFICATIONS:
CPU
AMD Ryzen™ Embedded V1500B 4-core/8-thread 2.2 GHz processor
CPU Architecture
64-bit x86
Floating Point Unit
✓
Encryption Engine
✓ (AES-NI)
System Memory
4 GB SODIMM DDR4 (1 x 4 GB)
Maximum Memory
64 GB (2 x 32 GB)
Memory Slot
2 x SODIMM DDR4Support ECC memory
For dual-DIMM configuration, you must use a pair of identical DDR4 modules.
Flash Memory
5GB (Dual boot OS protection)
Drive Bay
8 x 3.5-inch SATA 6Gb/s, 3Gb/s
The system is shipped without HDD.
Drive Compatibility
3.5-inch SATA hard disk drives2.5-inch SATA solid state drives
Hot-swappable
M.2 Slot
2 x M2 2280 (PCIe Gen3 x 1)
SSD Cache Acceleration Support
GPU pass-through
2.5 Gigabit Ethernet Port (2.5G/1G/100M)
2 (2.5G/1G/100M/10M)
Wake on LAN (WOL)
Only the 2.5GbE port
Jumbo Frame
PCIe Slot
1 x PCIe Gen3 x8
Card dimensions for PCIe slot：210 x 68.9x 18.76 mm / 8.27 x 2.71 x 0.74 inches.
USB 3.2 Gen 2 (10Gbps) Port
4 (2 x Type A, 2 x Type C)
Form Factor
2U Short Depth Rackmount
LED Indicators
HDD 1-8, Status, LAN, USB, Power
Buttons
Power, Reset
Dimensions (HxWxD)
89 × 482 × 297.4 mm
Excludes ear hook and the protruding part of the Power Supply Unit.
Weight (Net)
8.15 kg
Weight (Gross)
10.92 kg
Operating Temperature
0 - 40 °C (32°F - 104°F)
Storage Temperature
-20 - 70°C (-4°F - 158°F)
Relative Humidity
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Power Supply Unit
300W PSU(x2), 100 - 240V
Power Consumption: HDD Sleep Mode
32.19 W
Power Consumption: Operating Mode, Typical
58.14 W
Tested fully populated with WD10EFRX hard drives.
Fan
3 x 60mm, 12VDC
System Warning
Buzzer
Max. Number of Concurrent Connections (CIFS)
- with Max. Memory
2000
