CPU Architecture

64-bit ARM

Floating Point Unit

✓

Encryption Engine

✓

System Memory

4 GB SODIMM DDR4 (1 x 4 GB)

Maximum Memory

16 GB (1 x 16 GB)

Memory Slot

1 x SODIMM DDR4

Flash Memory

512 MB (Dual boot OS protection)

Drive Bay

5x 3.5-inch+ 4 x 2.5-inch SATA 6Gb/s

Drive Compatibility

3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives

2.5-inch bays:
2.5-inch solid state drives

Hot-swappable

✓

SSD Cache Acceleration Support

✓

2.5 Gigabit Ethernet Port (2.5G/1G/100M)

2 (2.5G/1G/100M/10M)

10 Gigabit Ethernet Port

2   x 10GbE SFP+

Wake on LAN (WOL)

Only the 2.5GbE port

Jumbo Frame

✓

USB 3.2 Gen 1 port

3

Form Factor

Tower

LED Indicators

System Status, LAN, USB, HDD1~5, SSD1-4

Buttons

Power,   Reset, USB Copy

Dimensions (HxWxD)

182.7 × 224.6 × 224.1 mm

Weight (Net)

3.39 kg

Weight (Gross)

4.99 kg

Operating Temperature

0   - 40 °C (32°F - 104°F)

Storage Temperature

-20 - 70°C (-4°F - 158°F)

Relative Humidity

5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)

Power Supply Unit

External, 120 W, AC 100 to 240 V

Power Consumption: HDD Sleep Mode

23.833 W

Power Consumption: Operating Mode, Typical

43.003 W

Tested with drives fully populated.

Fan

1 x 140mm, 12VDC

System Warning

Voice prompts or Buzzer

Kensington Security Slot

✓

Max. Number of Concurrent Connections (CIFS)

- with Max. Memory

700
