Image Sensor

1/3 Progressive Scan CMOS sensor

Day and Night

ICR type

LENS

Focal Length

4 mm

Aperture

F1.6

FOV

Horizontal FOV: 83.3°, Vertical FOV: 53.1°, Diagonal FOV: 91°

ILLUMINATOR

Supplementary Light

2 IR Lights, 2 Spotlights

Supplementary Light Distance

Up to 30 m/100 ft (depending on environment)

IR Wavelength

850nm

Night Vision Mode

Smart Mode, Full Color Mode, Black & White Mode

VIDEO

Video Encoding Format

H.265, H.264

Main Stream Resolution

2304 ×1296, 1920 × 1080, 1280 × 720

Sub Stream Resolution

640 × 360, 352 × 288

Frame Rate

1-30fps, Default 20fps

Bit Rate

512kbps -- 4096kbps

Bit Rate Control

CBR,VBR

AUDIO

Audio Encoding Format

G.711A, G.711U, AAC

Audio Sampling Rate

8 kHz

Audio Communication

Two-way Audio, Voice Input


Image Enhancement

DWDR, BLC, HLC, 3D DNR

Privacy Mask

4 Areas

NETWORK

Ethernet Port

1 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet port

ONVIF

Support

Protocols

TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, ARP, WebSockets

Client

TDSEE (mobile phone), TDSEE STUDIO (PC)

Web Browser

Plug-in free live view: Chrome, Edge, Opera

PAN&TILT

Pan Movement Range

0°--355°

Tilt Movement Range

0°--90°

Preset

6

Patrol

Panoramic Patrol, Preset Patrol

WI-FI

Antenna

Internal antenna

Wireless Standard

IEEE 802.11 b/g/n/ax

Transmission Rate

Up to 287Mbps

Channel Width

20/40 MHz

Modulation

DSSS/OFDM/OFDMA

Frequency Band

2.4GHz: 2412MHz-2472MHz(CH1-CH13)

Transmit Power

2.4GHz: <0.1W(EIRP)

Security

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK

ALARM

Smart Detection

Motion Detection, Tempering Detection, Human Detection, Vehicle Detection

Smart Linkage

Sound&light   Alert, Human Tracking

DIY Audio

3 Customized Audios

INTERFACE

Audio Input

Built-in MIC, adjustable microphone volume

Audio Output

Built-in Speaker, 79 dBA (Alarm sound at 1 meter), adjustable sound level

Storage

Built-in Micro SD Card Slot, Up to 512 GB

Reset Button

Support

LED Indicator

Dual Color (red & blue)

LED Indicator

GENERAL

Power

12 V DC, 1A, Ø5.5mm&Ø2.1mm Power Plug

Material

Plastic

Smart Integration

Amazon Alexa

Product Dimension

120mm x 120mm x 146mm (4.7'' × 4.7'' × 5.7'')

Package Dimension

167 mm x 131 mm x 251 mm (6.6'' × 5.2'' × 9.9'')

Product Weight

367g (0.81lb)

With Package Weight

860g (1.89lb)

Protection Level

IP65

Installation Method

Wall Mounting, Ceiling Mounting, Pole Mounting

Certification

CE, RoHS, FCC, RCM, UKCA

Temperature

Operating Temperature: -30°C ~ 60°C (-22°F ~ 140°F)

Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F)

Humidity

Operating Humidity: 10% ~ 95% RH (non-condensing)

Storage Humidity: 3% ~ 95% RH (non-condensing)

Package Contents

Camera

Power Adapter (cord length: 3m)

Installation Template

Mounting Bracket

Mounting Accessories Kit

Waterproof Kit

Quick Installation Guide
