HARDWARE |
|
Standard&Protocol | IEEE802.3, IEEE802.3u |
CPU | 600MHz |
RAM | 32MB |
Interfaces | 1*10/100Mbps WAN port 3*10/100Mbps LAN ports |
Antenna | 4*6dBi external antennas |
Button | 1* Wi-Fi / Reset button |
Power | Input：100-240V—50/60Hz 0.4A Output：DC 9V1A |
LED Indicator | Sys*1,WiFi*1, WAN*1, LAN*1 |
Dimension | 220mm*141.5mm*49mm(L*W*H) |
WIRELESS |
|
Wireless Standard | IEEE 802.11ac/a/n @5GHz IEEE 802.11b/g/n @2.4GHz |
Data Rate | 5GHz: Up to 867Mbps 2.4GHz: Up to 300Mbps |
Frequency | CE: 2.4G: 2412-2472MHz(CH1-CH13) 5G: 5150-5250MHz(CH36-CH64) FCC: 2.4G: 2412-2462MHz(CH1-CH11) 5G: 5150-5250MHz(CH36-CH64) 5725-5825MHz(CH149-CH165) |
Transmission Power | CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) FCC: <30 dBm (2.4 GHz) <30 dBm (5 GHz) |
Wireless Security | WPA2-PSK Wireless Security : Enable /Disable |
SOFTWARE |
|
Internet Connection Type | PPPoE, Dynamic IP, Static IP PPPoE(Russia), PPTP(Russia), L2TP(Russia) Unify,Maxis,Maxis-special,Celcom,Digi |
Network Protocol | IPv4&IPv6 |
Operating Mode | Router Mode AP Mode Universal Repeater Mode（Client+AP,WISP） |
Parental Control | Client Filter URL Filter Time Limit |
DHCP | DHCP Server DHCP Client List DHCP Static IP Address Reservation and Allocation |
Virtual Server | Port Forwarding, DMZ Host, UPnP |
Firewall | ICMP Flood Attack Defense TCP Flood Attack Defense UDP Flood Attack Defense Block Ping From WAN |
DDNS | DynDNS, no-ip, oray, 88ip |
VPN | IPsec pass through PPTP pass through L2TP pass through |
Special Features | Guest Network IPTV Signal Adjustment |
Basic Functions | PPPoE Username/password Clone Smart WiFi Schedule Smart Power Saving Smart LED on/off Tenda App Dual-band in One IPv6 Features Supported Broadband management MAC address clone Backup & Restore configurations Firmware upgrade from local |
OTHERS |
|
Temperature | Operating Temperature : 0℃~40℃ Storage Temperature : -40C ~70℃ |
Humidity | Operating Humidity : 10 %~90% RH non-condensing Storage Humidity : 5 %~ 90%RH non-condensing |
Certification | CE, FCC,RoHS |
Package Contents | Wi-Fi Router *1 RJ45 Ethernet Cable*1 Power Adapter*1 Quick Installation Guide*1 |
