Standard&Protocol

IEEE 802.3, IEEE 802.3u, IEEE 802.3ab

CPU

1.7GHz Quad-core CPU

RAM

256MB

Interface

3 x 10/100/1000Mbps RJ45 ports per node

Antenna

4 x 3dBi Internal antenna

Button

1 x Reset Button

1 x MESH Button

Power

Input: AC 100-240V, 50/60Hz

Output: DC 12 V ⎓ 1.5 A

LED Indicator

1 x Tri-color LED Indicator(Green,Yellow,Red)

Dimension

86x86x190mm (3.39 x3.39 x 7.48 in)

WIRELESS

Wireless Standard

5GHz: IEEE 802.11ax/ac/n/a

2.4GHz: IEEE 802.11ax/n/b/g

Data Rate

2.4GHz: 574Mbps (802.11ax)

5GHz: 2402Mbps (802.11ax)

Frequency

2.4GHz & 5GHz

Transmission Power

CE:

<20 dBm (2.4 GHz)

<23 dBm (5 GHz)

FCC:

<30 dBm (2.4 GHz)

<30 dBm (5 GHz)

Basic Functions

Beam Forming

MU-MIMO

AP Steering

Band Steering

OFDMA

1024-QAM

Wireless Security

WPA3-SAE/WPA2-PSK

SOFTWARE

Internet Connection Type

PPPoE, Dynamic IP, Static IP, PPPoE(Russia), PPTP(Russia), L2TP(Russia)

Network Protocol

IPv4&IPv6

Operating Mode

Router Mode,AP Mode

Parental Control

Client Filter

URL Filter

Time Limit

DHCP

DHCP Server

DHCP Client List

Virtual Server

Port Forwarding

DMZ Host

UPnP

Firewall

Forbid TCP/UDP flood attack

DNS

Support manually setting DNS server

VPN

PPTP Server,

PPTP/L2TP Client

Special Features

Ethernet Backhaul

IPv6

IPTV

Other Function

Support App and web management

Guest Network

Firmware upgrade online

OTHERS

Temperature

Operating Temperature : 0℃~40℃

Storage Temperature : -40C ~70℃

Humidity

Operating Humidity : 10 %~90% RH non-condensing

Storage Humidity : 5 %~ 90%RH non-condensing

Certification

CE, FCC, RoHS

Package Contents

Mesh32X*3

Quick Installation Guide*1

Gigabit Ethernet Cable*1

12/1A Power Adapter*3
