Image Sensor

1/3 Progressive Scan CMOS sensor

Day and Night

ICR type

LENS

Focal Length

4mm

Aperture

F2.0

FOV

Horizontal : 78°, Vertical : 41.8°, Diagonal : 95°

ILLUMINATOR

Supplementary Light

2 IR Lights

Supplementary Light Distance

Up to 10 m/32 ft (depending on environment)

IR Wavelength

850nm

Night Vision Mode

Black & White Mode

VIDEO

Video Encoding Format

H.265, H.264

Main Stream Resolution

2304 × 1296, 1920 × 1080, 1280 × 720

Sub Stream Resolution

640 x 360 , 352 x 288 , 320x240

Frame Rate

1-30fps, Default 20fps

Bit Rate

512kbps -- 4096kbps

Bit Rate Control

CBR,VBR

AUDIO

Audio Encoding Format

G.711A, G.711U, AAC

Audio Sampling Rate

8 kHz

Audio Communication

Two-way Audio, One-touch Call


Image Enhancement

DWDR, BLC, HLC, 3D DNR

Privacy Mask

4 Areas

NETWORK

ONVIF

Support

Protocols

TCP/IP, UDP, ICMP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, ARP

Client

TDSEE (mobile phone), TDSEE STUDIO (PC)

Web Browser

Chrome, Edge, Opera

PAN&TILT

Pan Movement Range

0°--355°

Tilt Movement Range

-65°--90°

Preset

6

Patrol

Panoramic Patrol, Preset Patrol

WI-FI

Antenna

Internal antenna

Wireless Standard

IEEE 802.11 b/g/n/ax

Transmission Rate

Up to 287Mbps

Channel Width

20/40 MHz

Modulation

DSSS/OFDM/OFDMA

Frequency Band

2.4GHz: 2412MHz-2472MHz(CH1-CH13)

Transmit Power

2.4GHz: <0.1W(EIRP)

Security

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK

ALARM

Smart Detection

Motion Detection, Tampering Detection, Human Detection, Cry Detection, Pet Detection

Smart Linkage

Sound&light Alert, Human Tracking

DIY Audio

3 Customized Audios

INTERFACE

Audio Input

Built-in MIC, adjustable microphone volume

Audio Output

Built-in Speaker, 68 dBA (Alarm sound at 1 meter), adjustable sound level

Storage

Built-in Micro SD Card Slot, Up to 512GB

Reset Button

Support

LED Indicator

Dual Color (red & blue)

LED Indicator

GENERAL

Power

5 V 1A, Type-C Power Plug

Material

Plastic

Smart Integration

Amazon Alexa

Product Dimension

103mm x 88mm x 88mm (4.1'' × 3.5'' × 3.5'')

Package Dimension

100mm x 100mm x 163mm (4.0'' × 4.0'' × 6.5'')

Product Weight

200g (0.44lb)

With Package Weight

370g (0.82lb)

Installation Method

Desktop, Ceiling Mounting

Certification

CE, RoHS, FCC, RCM, UKCA

Temperature

Operating Temperature: -10°C ~ 45°C (14°F ~ 113°F)

Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F)

Humidity

Operating Humidity: 10% ~ 95% RH (non-condensing)

Storage Humidity: 3% ~ 95% RH (non-condensing)

Package Contents

Camera

Power Adapter (cord length: 1.5m)

Installation Template

Mounting Bracket

Mounting Accessories Kit

Quick Installation Guide
