Processor Architecture

X.86 64-bit

Processor Frequency

10-Core (Max burst up to 4.7 GHz)

CPU Single-Core Score

/

Hardware Transcoding Engine

H.264, H.265, MPEG-4, VC-1;maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 60

Hardware Encryption Engine

√

System Memory

16 GB DDR5 non-ECC SODIMM

Pre-installed Memory Module

16 GB DDR5 non-ECC SODIMM (1x 16 GB)

Total Memory Slot Number

2 (DDR5 SODIMM)

Maximum Supported Memory

64 GB DDR5 non-ECC SODIMM

Note

TerraMaster reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Disk Slot Number

12

Compatible Drive types

3.5" SATA HDD

2.5" SATA HDD

2.5" SATA SSD

Maximum Internal Raw Storage Capacity

288 TB (24 TB x 12) (Capacity may vary by RAID types)

Drive Hot Swap

√

Note

Hard drive vendors will release their latest models of hard drives, and Maximum internal raw storage capacity may be adjusted accordingly.

The maximum single volume size is not directly related to the maximum raw capacity.

Internal Drive

Btrfs, EXT4

External Drive

EXT3, EXT4, NTFS, FAT32, HFS+

RJ-45 10GbE Network Jack

2

USB3.2 Host Port

Type A *3 (10Gbps) ; Type C *1 (10Gbps)

HDMI

1(HDMI 2.0)

PCIe Slots

1 (PCIe 3.0 x2）

M.2 2280 NVMe Slot

2 (PCIe 4.0 x4）

Size (H*W*D)

88 x 440 x 550 mm

Packaging Size (H*W*D)

217 x 580 x 710 mm

Weight

Gross Weight: 16.0 Kg

System Fan

80 x 80 x 38mm 3PCS

Fan Mode

Smart, High speed, Middle speed, Low speed

Noise Level

39.0 dB(A) （Using M.2 SSDs in standby mode; Test environment noise: 17.3dB(A); Test   distance: 1m）

Power Supply

550 W

AC Input Voltage

100V - 240V AC

Power Consumption

120.0 W (Fully loaded WD RED WD221KFGX 22TB hard drive(s) in read/write state)

33.0 W (Fully loaded WD RED WD221KFGX 22TB hard drive(s) in hibernation)

Certificate

FCC, CE, CCC, KC

Environment

RoHS, WEEE

Working Temperature

0°C  ~ 40°C   (32°F ~ 104°F)

Storage Temperature

-20°C ~ 60°C (-5°F ~ 140°F)

Relative Humidity

5% ~ 95% RH

Package Contents

Host unit (x1);Power cord (x1);Power Adapter(x1);RJ-45 network cable (x1);Quick Installation Guide (x1);Limited Warranty Note(x1);Screws(a few)

Supported Client OS

Windows OS, Mac OS, Linux OS

Supported Web Browsers

Google Chrome 97.0.xxxx, Mozilla Firefox 9.3, Apple Safari 12.1 ; Microsoft Edge 99.0.xx or later version.

Supported mobile OS

iOS14.0, Android 10.0 or later version

Supported RAID Types

TRAID, TRAID+, Single, JBOD, RAID 0, RAID 1, RAID5, RAID 6, RAID 10

Maximum Internal Volume Number

256

Maximum iSCSI Target

128

Maximum iSCSI LUN

256

Volume Expansion with Larger HDDs

TRAID, TRAID+, RAID5, RAID 6, RAID 10

RAID Migration

√

File Protocol

SMB/AFP/NFS/FTP/SFTP/WebDAV

Maximum Concurrent SMB/AFP/FTP/SFTP Connections

512

Maximum local user's account number

2048

Maximum local group number

512

Maximum shared folders number

512

Maximum shared folders syncing tasks

8

TCP/IP

IPv4/IPv6

Protocols

CIFS/SMB, NFS, FTP, SFTP, HTTPS, SSH, iSCSI, SNMP
