TP-Link 24 Port Gigabit Easy Smart Switch (TL-SG1024DE)

TP-Link 24 Port Gigabit Easy Smart Switch (TL-SG1024DE)
  • 27530_thumb_P_1563236331604
  • 27530_thumb_P_1563236348832
  • 27530_thumb_P_1563236349996
  • 27530_thumb_P_1563236349210
$112.0 Question Mark
Was: $133.0  WAS Tips    Save $21.0
or 4x fortnightly payments of $330 with ZipPay
Learn more
- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Click & Collect   Question Mark

Your store is set to:

Loading... Contact Store

   Monday Dispatch   Question Mark

Order within 69hrs and 17mins

Question Mark

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    TP-Link 24 Port Gigabit Easy Smart Switch (TL-SG1024DE)
  • Model Number:
    TL-SG1024DE
  • Brand:
  • Warranty Period:
    5 Year

Description

TP-Link TL-SG1024DE 24 Port Gigabit Easy Smart Switch


The TL-SG1024DE 24-Port Gigabit Easy Smart switch is an ideal upgrade from an unmanaged switch, designed for Small and Medium Business networks that require simple network management. Network administrators can effectively monitor traffic via Port Mirroring, Loop Prevention and Cable Diagnostics features. To optimize traffic on your business network, TL-SG1024DE offers Port-based/802.1p/DSCP QoS1 to keep latency-sensitive traffic moving smoothly and jitter-free. Additionally, port-based, tag-based and MTU VLAN can improve security and meet more network segmentation requirements. Moreover, with its innovative energy-efficient technology, the TL-SG1024DE can save up to 18% of power consumption, making it an eco-friendly solution for your business network.


  • 24 10/100/1000Mbps RJ45 ports

  • Provides network monitoring, traffic prioritization and VLAN features

  • Innovative energy-efficient technology reduces power output by up to 18%

  • Simple network set-up on top of plug-and-play connectivity

  • Web-based user interface and management utility simplify configuration

46461563236499

Specifications


HARDWARE FEATURES

STANDARDS AND PROTOCOLS

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE   802.3x, IEEE 802.1q, IEEE 802.1p

INTERFACE

24 10/100/1000Mbps RJ45 Ports
  AUTO Negotiation/AUTO MDI/MDIX

NETWORK MEDIA

10BASE-T: UTP category 3, 4, 5 cable (maximum   100m)
  EIA/TIA-568 100Ί STP (maximum 100m)
  100BASE-TX: UTP category 5, 5e cable (maximum 100m)
  EIA/TIA-568 100Ί STP (maximum 100m)
  1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
  EIA/TIA-568 100Ί STP (maximum 100m)

FAN QUANTITY

Fanless

POWER SUPPLY

100-240VAC, 50/60Hz

DIMENSIONS ( W X D X H )

11.6*7.1*1.7 in. (294*180*44 mm)

MOUNTING

Rack Mountable

MAX POWER CONSUMPTION

33.52W (220V/50Hz)

MAX HEAT DISSIPATION

114.37 BTU/h

PERFORMANCE

WIRELESS STANDARDS

IEEE 802.11b, IEEE 802.11g, IEEE 802.11n

SWITCHING CAPACITY

48Gbps

PACKET FORWARDING RATE

35.7Mpps

MAC ADDRESS TABLE

8K

PACKET BUFFER MEMORY

512KB

JUMBO FRAME

9KB

SOFTWARE FEATURES

QUALITY OF SERVICE

Support Port-based/802.1p/DSCP priority
  Support 4 priority queues
  Rate Limit
  Storm Control

L2 FEATURES

IGMP Snooping V1/V2/V3
  Static Link Aggregation
  Port Mirroring
  Cable Diagnostics
  Loop Prevention

VLAN

Supports up to 128 VLANs simultaneously (out   of 4K VLAN IDs)
  MTU/Port/Tag VLAN

TRANSMISSION METHOD

Store-And-Forward

OTHERS

CERTIFICATION

FCC, CE, RoHS

PACKAGE CONTENTS

TL-SG1024DE, Power Cord, Installation Guide,   Resource CD, Rackmount Kit, Rubber Feet

SYSTEM REQUIREMENTS

MicrosoftÂŽ WindowsÂŽ for running Utility

ENVIRONMENT

Operating Temperature: 0℃~40℃   (32℉~104℉)
  Storage Temperature: -40
℃~70℃   (-40℉~158℉)
  Operating Humidity: 10%~90% non-condensing
  Storage Humidity: 5%~90% non-condensing

WARRANTY

Limited 3-Year Warranty

  For further information on our warranty policy please visit:   http://www.tp-link.com.au/support/rma
