Image Sensor

1/2.8“ Progressive Scan CMOS Sensor

Lens

Focal Length: 6 mm ± 5%, 2.53 mm±5%

Aperture: F1.6 ± 10%, F1.6 ± 10%

Field of View: 66.5° (Diagonal), 57.3° (Horizontal), 31.7° (Vertical);

165.1° (Diagonal), 137.6° (Horizontal), 73.0° (Vertical)

Night Vision

850 nm IR LED (99 ft / 29.9 m), Color Night Vision

Day/Night Switch

IR-Cut Filter with Auto-Switching

Interface & Button

1× RJ45 (10M/100M) Ethernet Port

1× RESET Button

1× microSD Card Slot (Up to 512 GB)

VIDEO & AUDIO

Maximum Resolution

2K 3MP (2304 x 1296 px) + 2K 3MP (2304 x 1296 px)

Frame Rate

15 fps

Video Compression

H.264

Live View

Yes

Image Enhancement

3DNR

WDR

Audio Input & Output

Built-in Microphone and Speaker

Audio Communication

Two-Way Audio with Noise Cancellation

Siren Volume

STORAGE

99 dB (Level measured at 4-inch/10-cm distance)

Local Storage

microSD Card Slot on Camera (Up to 512 GB)

* MicroSD card needs to be purchased separately. Actual storage capacity depends on the size of the microSD card used.

Cloud Storage

Tapo Care Cloud Storage Services (Subscription required)

DETECTION AND NOTIFICATIONS

AI   Detection

Motion Detection

Person Detection

Pet Detection

Vehicle Detection

Line-Crossing Detection

CameraTampering

Activity Zones

Yes

* Only works with Motion/Person/Pet/Vehicle Detection.

Output Notification

System Notification

System Notification with Snapshot (Tapo Care Services)

NETWORK

Network Connectivity

Connect via Wi-Fi or Ethernet

Wireless Connectivity

IEEE 802.11 b/g/n/ax, 2.4 GHz

Protocol

TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP

Ethernet Port

Yes

RTSP

Yes

ONVIF

Yes

Transmission Rate

11b: 11 Mbps

11g: 54 Mbps

11n: 72.2 Mbps

11ax: 143.4 Mbps

SECURITY

Security

On-Device Machine Learning

128-bit AES Encryption with SSL/TLS

WPA/WPA2-PSK/WPA3

POWER

Power Source

12 V DC Power Adapter

Input Voltage

100-240 V, 50/60 Hz

Output Voltage

12 V, 1 A (DC Power)

DC Power Connector Size

Inside Ø: 2.1 mm

Outside Ø: 5.5 mm

Power Cord Length

3 m

Typical Power Consumption

5.3 W

Maximum Power Consumption

11.2 W

GENERAL

Smart Integration

Google Assistant, Amazon Alexa, Samsung SmartThings

Weather Resistance

IP66

Mounting Options

Wall-Mounted

Eave-Mounted

Pole-Mounted

Operating Temperature

-30 ºC ~ 60 ºC (-22 °F ~ 140 °F )

Storage Temperature

-40 ºC ~ 60 ºC (-40 °F ~ 140 °F)

Operating Humidity

10% ~ 90% RH, Non-condensing

Storage Humidity

0 ~ 90% RH, Non-condensing

Dimensions ( W x D x H )

4.51 × 6.28 × 5.99 in (114.57 × 159.55 × 152.1 mm)

Weight

17.32 oz / 491 g

Package Content

TC47 Camera ×1

Mounting Bracket ×1

Mounting Template Sticker ×1

Mounting Screws ×4

Mounting Anchors ×4

Waterproof Seal ×1

Waterproof Cable Attachments ×1

Power Adapter ×1

Quick Start Guide
