Interface

8 10/100/1000Mbps RJ45 Ports

AUTO Negotiation/AUTO MDI/MDIX

Network Media

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

100BASE-TX: UTP category 5, 5e cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)

EIA/TIA-568 100Ω STP (maximum 100m)

Fan Quantity

1

Physical Security Lock

No

Power Supply

100-240VAC, 50/60Hz

Packet Forwarding Rate

11.904 Mpps

PoE Ports (RJ45)

Standard: 802.3af/at compliant

PoE+ Ports: 8 Ports

Power Supply: 153W

Mac Address Table

4K

Buffer Size

1.5Mbits

Jumbo Frame

16 KB

Switching Capacity

16Gbps

Dimensions ( W x D x H )

11.6*7.1*1.7 in. (294*180*44 mm)

Mounting

Desktop/Rack   Mountable

Max. Power Consumption

• 172.49 W(110V/60Hz. with 153W PD connected)

• 8.77 W(220V/50Hz. no PD connected)

Max. Heat Dissipation

• 29.91 BTU/h(no PD connected)

• 588.19 BTU/h(with 153W PD connected)

SOFTWARE FEATURES

Advanced Features

• Compatible With IEEE 802.3af/at Compliant PDs

• Priority Function

• Mac Address Auto-Learning And Auto-Aging

• IEEE802.3x Flow Control for Full-Duplex Mode and Backpressure for Half-Duplex   Mode

• Extend Mode Button (Ports 1–2, Up to 250 m PoE power supply and data   transmission)

• PoE Auto Recovery (Ports 1-8)

Transmission Method

Store-And-Forward

OTHERS

Certification

FCC, CE, RoHS

Package Content

TL-SG1008MP, Power Cord, Installation Guide, Rackmount Kit, Rubber Feet

Environment

Operating Temperature: 0℃~50℃ (32℉~122℉)

Storage Temperature: -40℃~70℃ (-40℉~158℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
