Omada App

Yes

Centralized Management

• Omada Central (Cloud-Based)

• Omada Hardware Controller

• Omada Software Controller

Cloud Access

Yes. Require the use of an Omada controller.

Email Alerts

Yes

LED ON/OFF Control

Yes

Management MAC Access Control

Yes

SNMP

v1, v2c, v3

System Logging Local/Remote Syslog

Local/Remote Syslog

SSH

Yes

Web-based Management

HTTP/HTTPS

L3 Management

Yes

Multi-site Management

Yes

Management VLAN

Yes

Zero-Touch Provisioning

Yes. Requiring the use of Omada Cloud-Based Controller

HARDWARE FEATURES

Interface

1× Gigabit Ethernet Port

Button

Reset

Power Supply

V4:

• 802.3af PoE

• 48 V Passive PoE

• 12 V/1 A DC (Power Adapter included)

Max. Power Consumption

10.9W (For PoE);

9.9W (For DC)

Dimensions ( W x D x H )

V2 and above: 6.3 × 6.3 × 1.3 in (160 × 160 × 33.6 mm)

Antenna

Internal Omni Antenna

• 2.4 GHz: 2× 4 dBi

• 5 GHz: 2× 5 dBi

Mounting

• Ceiling/Wall Mounting (Kits included)

• Junction Box Mounting

WIRELESS FEATURES

Coverage

115㎡(1250 ft²)***

* Coverage   value is calculated based on laboratory testing. Actual coverage is not   guaranteed and will vary as a result of client limitations and environmental factors.

Concurrent Clients

250+**

** The actual capacity depends on the wireless environment and client traffic and is   generally less than the maximum number of client connections.

Wireless Standards

IEEE 802.11ax/ac/n/g/b/a

Frequency

2.4 GHz and 5 GHz

Signal Rate

• 5 GHz: Up to 1201 Mbps

• 2.4 GHz: Up to 574 Mbps

Wireless Functions

• 1024-QAM

• 4× Longer OFDM Symbol

• OFDMA

• Multiple SSIDs (Up to 16 SSIDs, 8 for each band)

• Enable/Disable Wireless Radio

• Automatic Channel Assignment

• Transmit Power Control (Adjust Transmit Power on dBm)

• QoS(WMM)

• MU-MIMO

• Seamless Roaming(802.11k/v/r)§

• Omada Mesh§

• Band Steering

• Load Balance

• Airtime Fairness

• Beamforming

• Rate Limit

• Reboot Schedule

• Wireless Schedule

• Wireless Statistics based on SSID/AP/Client

Wireless Security

• Captive Portal Authentication§

• Access Control

• Wireless Mac Address Filtering

• Wireless Isolation Between Clients

• SSID to VLAN Mapping

• Rogue AP Detection

• 802.1X Support

• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

Transmission Power

• CE:

7-20 dBm(2.4 GHz, EIRP)

7-23 dBm(5 GHz, U-NII-1 & U-NII-2A, EIRP) ; 7-27 dBm (5 GHz U-NII-2C, EIRP)

• FCC:

4-24 dBm (2.4 GHz)

4-24 dBm (5 GHz, U-NII-1 & U-NII-3)

OTHERS

Certification

CE, FCC, RoHS

Package Content

• EAP610

• Power Adapter

• Ceiling/Wall/Junction Box Mounting Kits

• Installation Guide

System Requirements

Microsoft   Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux

Environment

• Operating Temperature: 0–40 ℃ (32–104 ℉)

• Storage Temperature: -40–70 ℃ (-40–158 ℉)

• Operating Humidity: 10–90% RH non-condensing

• Storage Humidity: 5–90% RH non-condensing
