Network Type

LTE Band of EU:

4G LTE-FDD: B1/B3/B5/B7/B8/B20/B28/B32 (2100/1800/850/2600/9

00/800/700/1450 MHz)

4G LTE-TDD: B38/B40/B41 (2600/2300/2500 MHz)

3G DC-HSDPA/HSPA+/HSDPA/HSUPA/WCDMA: B1/B3/B5/B8

(2100/1800/850/900 MHz)

Carrier Aggregation:

B1+B1/B3/B5/B7/B8/B20/B28/B38/B40/B41

B3+B3/B5/B7/B8/B20/B28/B38/B40/B41

B5+B5/B7/B38/B40/B41

B7+B7/B8/B20/B28/B32

B8+B32/B38/B40/B41

B20+B32/B38/B40

B28+B32/B38/B40/B41

B38+B38

B40+B40

B41+B41

SIM Type

1× Nano SIM Card

Frequency

• Downlink: 300 Mbps;

• Uplink: 50 Mbps

SECURITY

DPI

Application control via DPI / Updated app library

Access Control

Source/Destination IP Based Access Control

Filtering

• Web Group Filtering

• URL Filtering

• Web Security

ARP Inspection

• Sending GARP Packets

• ARP Scanning

• IP-MAC Binding

Attack Defense

• TCP/UDP/ICMP Flood Defense

• Block TCP Scan (Stealth FIN/Xmas/Null)

• Block Ping from WAN

HARDWARE FEATURES

Interface

• 3 Gigabit WAN/LAN Ports

Network Media

• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)

• 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)

• 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)

Button

Reset Button

Power Supply

802.3at/bt PoE; 12VDC / 2A Power Adapter

Wi-Fi Frequency & Signal Rate

• 2.4 GHz: 574 Mbps

• 5 GHz: 2402 Mbps (HE160)

Flash

256 MB NAND

DRAM

512 MB DDR4

LED

4G Signal, WLAN, WAN/LAN, SYS

Dimensions ( W x D x H )

6.9 × 4.0 × 1.5 in (174.8 × 100.4 × 38.7 mm) (Antenna dimensions are not included)

Antenna

• Wi-Fi: Two 5GHz 4.0dBi & 2.4GHz 2.3 dBi dual-band build-in antennas

• LTE: Two 4.0dBi omnidirectional detachable antennas

Mounting

Pole/Wall-Mounting

Max Power Consumption

POE:62.9W max @ 220V/50Hz 25℃

DC: 16.6W max @ 220V/50Hz 25℃

PERFORMANCE

DPI Throughput

• TCP: 1131 Mbps

• UDP: 974 Mbps

GRE

• Unencrypted: 450.3Mbps

• Encrypted: 277.6Mbps

WireGuard VPN

462.8Mbps

Concurrent Session

120,000

New Sessions /Second

3,800

NAT (Static IP)

945.9Mbps / 950.2Mbps

NAT(DHCP)

947.3Mbps / 949.4Mbps

NAT(PPPoE)

916.9Mbps / 946.3Mbps

NAT (L2TP)

878.9Mbps / 778.9Mbps

NAT (PPTP)

852.2Mbps / 775.9Mbps

IPsec VPN Throughput

• ESP-SHA1-AES256: 568.3Mbps

• ESP-SHA256-AES256: 559.8Mbps

• ESP-SHA384-AES256: 565.6Mbps

• ESP-SHA512-AES256: 550.0 Mbps

OpenVPN

85.1Mbps

L2TP VPN Throughput

• Unencrypted: 858.7Mbps

• Encrypted: 467.0Mbps

PPTP VPN Throughput

• Unencrypted: 876.2Mbps

• Encrypted: 182.6Mbps

SSL VPN Throughput

86.6Mbps

66 Byte Packet forwarding rate

1,453,489 pps / 1,453,489 pps

1,518 Byte Packet forwarding   rate

81275 pps / 81275 pps

WIRELESS FEATURES

Advanced Functions

• Seamless Roaming

• Mesh (with EAP that supports Mesh)

• OFDMA

• Beamforming

• MU-MIMO

• Rate Limit: Based on SSID/Client

• Airtime Fairness

• Wireless Encryption: WPA/WPA2/WPA3 Personal, WPA/WPA2/WPA3   Enterprise

• Multiple SSIDs: 16 in total (8 per radio)

Guest Network

Support

BASIC FUNCTIONS

WAN Connection Type

• Static IP

• Dynamic IP

• PPPoE (supports MRU Configuration)

• PPTP

• L2TP

MAC Clone

Modify WAN Address

DHCP

• DHCP Server

• DHCPv6 PD Server (only in Standalone Mode)

• DHCP Options Customization

• DHCP Address Reservation

• Multi-IP Interfaces

• Multi-Net DHCP

SMS

Receive / Send SMS

IPv6

StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode

VLAN

802.1Q VLAN

IPTV

IGMP v2/v3 Proxy, Custom Mode, Bridge Mode

ADVANCED FUNCTIONS

ACL

IP/Port/Protocol/Domain Name Filtering

Advanced Routing

• Static Routing

• Policy Routing

• RIP

• OSPF

Bandwidth Control

IP-Based Bandwidth Control

Load Balance

• Intelligent Load Balance

• Application Optimized Routing

• Link Backup(Timing, Failover)

• Online Detection

NAT

• One-to-One NAT

• Multi-Net NAT

• Virtual Server

• Port Triggering

• NAT-DMZ

• FTP/H.323/SIP/IPSec/PPTP ALG

• UPnP

Session Limit

IP-Based Session Limit

VPN

GRE

Only in Standalone Mode

SSL VPN

50 Tunnels

IPsec VPN

• 100 IPSec VPN Tunnels

• LAN-to-LAN, Client-to-LAN

• Main, Aggressive Negotiation Mode

• DES, 3DES, AES128, AES192, AES256 Encryption Algorithm

• IPsec Failover

• IKE v1/v2

• MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm

• NAT Traversal (NAT-T)

• Dead Peer Detection (DPD)

• Perfect Forward Secrecy (PFS)

PPTP VPN

• PPTP VPN Server

• PPTP VPN Client (10)

• 50 Tunnels

• PPTP with MPPE Encryption

L2TP VPN

• L2TP VPN Server

• L2TP VPN Client (10)

• 50 Tunnels

• L2TP over IPSec

OpenVPN

• OpenVPN Server

• OpenVPN Client (5)

• 55 OpenVPN Tunnels

• "Certificate + Account" Mode

• Full Mode

WireGuard VPN

• 20 Tunnels

AUTHENTICATION

Web Authentication

• No Authentication

• Simple Password

• Hotspot (Local User / Voucher / SMS / Radius)

• External Radius Sever

• External Portal Sever

• LDAP

MANAGEMENT

Omada App

Yes.

Centralized Management

• Omada Cloud Essentials

• Omada Cloud-Based Controller

• Omada Hardware Controller (OC300)

• Omada Hardware Controller (OC200)

• Omada Software Controller

Cloud Access

Yes.

Service

Dynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)

Maintenance

• Web Management Interface

• Remote Management

• Export & Import Configuration

• SNMP v1/v2c/v3

• Diagnostics (Ping & Traceroute)

• NTP Synchronize

• Port Mirroring

• CLI (only in Standalone Mode)

• Syslog Support

Management Features

• Automatic Device Discovery

• Intelligent Network Monitoring

• Abnormal Event Warnings

• Unified Configuration

• Reboot Schedule

• Captive Portal Configuration

OTHERS

Certification

CE, FCC, RoHS

Package Contents

• ER703WP-4G-Outdoor

• Mounting Kits

• Quick Installation Guide

System Requirements

• Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11

• MAC OS, NetWare, UNIX or Linux

Environment

• Operating Temperature: -30 °C to 60 °C (-22 °F to 140 °F)

• Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)

• Operating Humidity: 5% to 95% non-condensing

• Storage Humidity: 5% to 90% non-condensing

Notes

*Actual 4G downlink speeds vary between buildings. Factors affecting 4G speeds include the internet service plan, real-time network capacity, equipment and client limitations, and environmental factors.

Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary.

ΔThe Omada cloud-based controller offers the Essentials version of cloud services for free, while the Standard version, which includes advanced features, requires a license.

§GRE VPN is supported only in Standalone Mode.

#Use of Wi-Fi 6 and other features including OFDMA, MU-MIMO, 1024-QAM, and BSS Color requires clients to also support the corresponding features.

**Protection against lightning may be achieved through proper product setup, grounding, and cable shielding. Refer to the instruction manual and consult an IT professional to assist with setting up this product.
