Built-In Omada OS Applications

Network Application

Managed Omada Devices

Recommended for up to 30 devices

Client Capacity

Recommended for up to 300 connected clients

Interface

• 1× 2.5G RJ45 WAN port

• 4× 2.5G RJ45 LAN/WAN ports

• Up to 4 simultaneous WAN ports

IPS Throughput

2,183 Mbps

Site-to-Site VPN Throughput

1,023 Mbps*

* Performance data is based on IPsec VPN.

Management

Cloud, local, and Omada App management

Mounting

• Desktop

• Wall-mount (magnetic-mount plate sold separately)

• Rack-mount (rackmount kit sold separately)

Dimensions

6.3 × 5.12 × 1.24 in (160 × 130 × 31.5 mm)

BUILT-IN OMADA CONTROLLER§

Cloud Access

√

Local Management

√

Omada App

√

Multi-Site Management

Via the Omada Cloud Management Platform

Restore & Backup

√

Automatic Device Discovery

√

Network Topology

√

Dashboard

√

Device List / Client List

√

Logs / Alerts / Events

√

Batch Firmware Upgrade

√

Health Monitoring

√

Internet Activity

√

Captive Portal

√

RADIUS / LDAP Authentication

√

802.1X Authentication

√

OUI-Based VLAN

√

Diagnostics Tools

Ping Test, Packet Capture, Terminal, Cable Test, Interference Detection, Remote   Access, IntelliRecover, Port Mirroring

SNMP

v1/v2c/v3

SECURITY

IDS/IPS

√

DPI

√

Application-Based ACL

√

Content Filtering

√

Ad Blocker

√

Safe Search

√

DNS Security

√

Firewall

√

Attack Defense

√

ARP Inspection

√

VPN & SD-WAN

Omada LightLink VPN

√

Site-to-Site VPN

WireGuard VPN / IPsec VPN

VPN Server

WireGuard VPN / OpenVPN / IPsec VPN / SSL VPN / L2TP VPN / PPTP VPN

VPN Client

WireGuard VPN / OpenVPN / L2TP VPN / PPTP VPN

SD-WAN

Full Mesh Mode

VPN Throughput

• Omada LightLink VPN: 527 Mbps

• IPsec VPN: 1,023 Mbps

• WireGuard VPN: 605 Mbps

• OpenVPN: 223 Mbps

• L2TP VPN: 892 Mbps

• PPTP VPN: 193 Mbps

• SSL VPN: 250 Mbps

NETWORKING

WAN Connection

Static IP / Dynamic IP / PPPoE / PPTP / L2TP / MAP-E / DS-Lite

Multi-WAN Failover & Load Balancing

√

DHCP Server

√

VLAN Segmentation

√

Bandwidth Control

√

QoS

√

Static Routing

√

Policy Routing

√

NAT

Port Forwarding / Virtual Server / DMZ / ALG / UPnP / One-to-One NAT / Disable NAT

Dynamic DNS

TP-Link DDNS, 3rd-party DDNS, custom DDNS

IPv6

Static IP / SLAAC / DHCPv6 / PPPoE / 6to4 Tunnel / Pass-Through / Non-Address Mode

Bonjour / mDNS

√

IGMP v2/v3 Proxy

√

HARDWARE

Touchscreen

2.51-inch color LCM touchscreen

Button

Reset button

CPU

Quad-core ARM Cortex-A53 @ 2.0 GHz

Memory

2 GB DDR4

Storage

64 Mbit NOR flash + 16 GB eMMC

Power Supply

USB-C power adapter, 100–240 V AC, 50/60 Hz input, 5 V DC / 3 A output

Max Power Consumption

8.18 W, with power adapter

Enclosure

Polycarbonate

LED

Ethernet

Fan

Fanless

Net Weight

1.12 lb (510 g)

Surge Protection

4 kV surge protection

ESD Protection

±8 kV (Air), ±4 kV (Contact)

Onboarding

Bluetooth or Ethernet

Certifications

CE, FCC, RoHS

Environment

• Operating Temperature: 14 °F to 104 °F (-10 °C to 40 °C)

• Storage Temperature: -40 °F to 158 °F (-40 °C to 70 °C)

• Operating Humidity: 10% to 90% RH, non-condensing

• Storage Humidity: 5% to 90% RH, non-condensing
