Image Sensor

1/3" Progressive Scan CMOS Starlight Sensor

Lens

Focal Length: 2.1 mm

Aperture: F2.1

Field of View: 150° (Diagonal), 134°(Horizontal), 77°(Vertical)

Night Vision

850 nm IR LED (49 ft / 15 m)

Full-Color Night Vision

Lighting

4× Built-in IR LED

4× Built-in WHITE LED

Interface & Button

1* switch button

1* reset button

1* MicroSD Card Slot

SOLAR PANEL

Connection Capacity

A solar panel can only connect to one camera

Output Port

Type-C

*A Type-C to Micro USB adapter (Included) is required for a camera with a Micro USB charging port

VIDEO & AUDIO

Maximum Resolution

2K QHD 4MP (2560 × 1440 px)

Frame Rate

15/20/(25/30)fps

Video Compression

H.264

Live View

YES

Image Enhancement

3DNR

WDR

Audio Input & Output

Built-in Microphone and Speaker

Audio Communication

Two-Way Audio with Noise Cancellation

Siren Volume

94 dB (Level measured at 4-inch/10-cm distance)

STORAGE

Local Storage

Supports microSD Card (Up to 512GB)

(Purchase Separately)

Cloud Storage

Tapo Care Cloud Storage Services (Subscription required)

DETECTION and NOTIFICATIONS

Sensor

Single Motion Sensor (FOV: 130° horizontal)

Single Ambient

Light Sensors

AI Detection

Motion Detection

Person Detection

Pet Detection

Vehicle Detection

Activity Zones

Yes

Output Notification

System Notification

System Notification with Snapshot (Tapo Care Services)

NETWORK

Network Connectivity

Connect via Wi-Fi

Wireless Connectivity

IEEE 802.11b/g/n, 2.4 GHz Wi-Fi

SECURITY

Security

128-bit AES Encryption with SSL/TLS

WPA/WPA2-PSK

POWER

Power Source

10000 mAh Built-in Rechargeable Lithium-ion Battery

Solar Panel: Tapo A201

Input Voltage

Adapter Input: 100-240 V, 50/60 Hz (Not included)

Output Voltage

Adapter Output: 5.0 V, 2.0 A (Not included)

Solar Panel Max Charging Voltage: 5.2 V

Solar Panel Max Charging Power: 2.5 W

GENERAL

Smart Integration

Google Assistant, Amazon Alexa

Weather Resistance

IP66

System Requirements

Tapo App: iOS 9.0 or higher, Andriod 4.4 or higher

Mounting Options

Ceiling-Mounted, Wall-Mounted

Operating Temperature

-20℃~45℃

Storage Temperature

-20℃~60℃

Operating Humidity

10%~90% RH, Non-condensing

Storage Humidity

5%~90% RH, Non-condensing

Charging Temperature

0-45℃

Dimensions ( W x D x H )

Camera Dimensions:

D64.76mm*116.16mm (Without Brackets)

Solar Panel Dimensions:

173.42 × 120.42 × 15.7 mm (6.83 × 4.74 × 0.62 in)

Package Content

TC85 Camera × 1

Tapo A201 Solar Panel × 1

Camera Bracket × 1

Extension Wire × 1

Decorative Cover Plate × 1

Mounting Template × 1

Type-C to Micro USB Adapter × 1

Mounting Anchors × 6

Mounting Screws × 6

Waterproof Seals × 2

Battery Charger Cable × 1

Cable Tie × 1

Screw Caps × 2

Quick Start Guide

Certifications

CE, FCC, DOE, CEC, RCM, KC, NCC, BSMI, NTRA
