Image Sensor

1/2.8“ Progressive Scan CMOS Sensor

Lens

Lens: Wide Angle

Focal Length: 2.53 mm

Aperture: F1.6

Field of View: 165.1° (Diagonal), 137.6°(Horizontal), 73°(Vertical)

Lens: Telephone

Focal Length: 6mm

Aperture: F1.6

Field of View: 65.5° (Diagonal), 56.5°(Horizontal), 30.6°(Vertical)

Night Vision

850   nm IR LED (33 ft / 10 m)

Color

Night Vision

Lighting

6× Built-in Spotlights

Motion Activated, App-Controlled

2× Alarm Lights

1× Indicator LED

Interface & Button

1× POWER Button

1× RESET Button

1× MicroSD Card Slot (Up to 512 GB)

Pan/Tilt Range

Pan Mechanical Range: 334° (360° Pan Coverage)

Tilt Mechanical Range: 90° (120° Tilt Coverage)

SOLAR PANEL

Output

Solar Panel Max Charging Voltage: 5.2 V

Solar Panel Max Charging Power: 2.5 W

Output Port

Type-C

VIDEO & AUDIO

Maximum Resolution

Fixed Lens: 2K 3MP (2304 × 1296 px)

Pan/Tilt Lens: 2K 3MP (2304 × 1296 px)

Frame Rate

15fps

Digital Zoom

10.8×

Live View

Yes

Image Enhancement

3D DNR

BLC

WDR

Audio Input & Output

Built-in Microphone and Speaker

Audio Communication

Two-Way Audio with Noise Cancellation

Siren Volume

91.5 dB (Level measured at 10 cm distance)

64.4 dB (Level measured at 300 cm distance)

STORAGE

Local Storage

MicroSD Card Slot on Camera  (Up to 512 GB)

Cloud Storage

Tapo Care Cloud Storage Services (Subscription required)

DETECTION AND NOTIFICATIONS

Sensor

Three Motion Sensors

Ambient Light Sensor

AI Detection

Motion Detection

Person Detection

Pet Detection

Vehicle Detection

Activity Zones

Yes

Output Notification

App Notifications of Camera Event

App Notification of AI Detection Event with Snapshot (Subscription Required)

NETWORK

Network Connectivity

Connect via Wi-Fi

Wireless Connectivity

IEEE 802.11b/g/n, 2.4 GHz Wi-Fi

IEEE 802.11a/n, 5GHz Wi-Fi

Ethernet Port

No

RTSP

No

ONVIF

No

SECURITY

Security

128-bit AES Encryption with SSL/TLS

WPA/WPA2-PSK/WPA3-PSK

POWER

Power Source

10000 mAh Built-in Rechargeable Lithium-ion Battery

Solar Panel: Tapo A201

Input Voltage

Camera Input Voltage: 5V (DC)

GENERAL

Smart Integration

Google Assistant, Amazon Alexa

Weather Resistance

IP65

System Requirements

Tapo App: iOS 12.0 or higher, Android 7.0 or higher

Mounting Options

Ceiling-Mounted

Wall-Mounted

Pole-Mounted (Pole-Mounting loops required but not included)

Operating Temperature

-20℃ to 45℃ (-4°F to 113°F)

Storage Temperature

–40°C to 60°C (–40°F to 140°F)

Operating Humidity

10%~90% RH, Non-condensing

Storage Humidity

0%~90% RH, Non-condensing

Charging Temperature

0°C to 45°C (32°F to 113°F)

Dimensions ( W x D x H )

Camera Dimensions: 5.19 × 3.22 × 6.31 in (132 × 82 × 160 mm)

Solar Panel Dimensions: 6.82 × 4.74 × 0.61 in (173 × 120 × 15.5 mm)

Package Content

TC93D Camera ×1

Tapo A201 Solar Panel ×1

Solar Panel Bracket ×1

Base Cover ×1

USB Adapter Cable ×1

Extension Wire ×1

Cable Zip Tie ×1

Mounting Screws and Anchors

Mounting Template Stickers

Quick Start Guide

Certifications

FCC, WWA, NCC, BSMI, DOE, CEC, IP65, RoHS
