Dimensions

135 x 185 x 32 mm

(5.3 x 7.3 x 1.3")

Mobile Unlock

✓

NDAA Compliant

✓

UL 294 Level

Destructive attack: Level I

Line security: Level I

Endurance: Level I

Standby power: Level I

MECHANICAL

Weight

168 g (5.9 oz)

Enclosure Material

Glass, polycarbonate

Mount Material

Aluminum alloy

Mounting

Wall (Included)

Gang box mount (Optional)

HARDWARE

Indoor and Outdoor Use

Indoor only

Networking Interface

(1) 10/100 Mbps RJ45 port

Connectivity

Ethernet

Power Method

PoE

UL 294 Power-limited Class 2 PSU

UL 60950-1/62368-1 LPS/PS2 PSU

Max. Power Consumption

5W

Supported Voltage Range

44–57V DC

Display

Size

127 mm (5") diagonal

Luminance

300 nits (Typical)

Screen Orientation

Portrait

Resolution

1280 x 720 px

Microphone

✓

Speaker

✓

Buttons

(1)   Factory reset

PoE Cabling Requirements

Cat 5e cabling is the minimum performance category recommended. The performance category utilized should match the transmission speed required at the installation site.

The minimal conductor gauge permitted to connect between the PSE or power injector and the PD shall be 26 AWG (0.13 mm² ) for patch cords; 24 AWG (0.21 mm² ) for horizontal or riser cable.

UL 294 Statement

Compliance with IEEE 802.3 specifications was not verified as part of UL 294.

The equipment is intended to comply with the section of the National Electrical Code, ANSI/NFPA 70, Article 725.121, Power Sources for Class 2 and Class 3 Circuits.

CAN/ULC-60839-11-1 Grade

Grade assignment: I

Certifications

CE, FCC, IC, UL 294, CAN/ULC-60839-11-1

Document number, and issue date and/or revision level

UA-Intercom-Viewer, V01

Ambient Operating Temperature

0 to 40° C

(32 to 104° F)

Ambient Operating Humidity

5 to 95% noncondensing

SOFTWARE

Management Application

Access

Software Information

The software version can be checked at https://unifi.ui.com
