Compatibility

PC Resolution (max): 5120x2880

Mac® Resolution (max): 5120x2880

PC Operating System: Windows 10/11 certified; macOS tested

Mac® Resolution (min): 5120x2880

Connector

USB 3.2 Type A Down Stream: 2

USB 3.2 Type C Down stream: 1 (15W power charger)

USB 3.2 Type C Up Stream: 1

Thunderbolt™ 4 Up Stream: 1 (100W power charger)

Thunderbolt™ 4 Down Stream: 1 (15W power charger)

HDMI 2.1: 1

DisplayPort: 1

Power in: DC Socket (Center Positive)

Audio

Internal Speakers: 5Watts x2

Power

Eco Mode (Conserve): 37W

Eco Mode (optimized): 41W

Consumption (typical): 47W

Consumption (max): 50W

Voltage: AC 100-240V

Stand-by: 0.5W

Power Supply: External Power Adaptor

Additional Hardware

Kensington Lock Slot: 1

Controls

Physical Controls: Joystick key: Up, Right, Down, Left, Center; Power

On Screen Display: Input Select, Color Mode, ViewMode, Audio Adjust, Setup Menu

Operating Conditions

Temperature: 32°F to 104°F (0°C to 40°C)

Humidity (non-condensing): 20% to 90%

Wall Mount

VESA Compatible: 100 x 100 mm

Input Signal

Frequency Horizontal: 15.8 ~ 223.73KHz

Frequency Vertical: 24 ~ 75Hz

Video Input

Digital Sync: PCI-E - DisplayPort (v1.4), FRL - HDMI (v2.1), PCI-E - TBT4, Micro-Packet - Type C

Ergonomics

Height Adjust (mm): 120

Swivel: 60º

Tilt (Forward/Back): -5º / 22º

Pivot (Right/Left): 90º / 90º

Weight (imperial)

Net (lbs): 14

Net Without Stand (lbs): 9.3

Gross (lbs): 23.4

Weight (metric)

Net (kg): 6.4

Net Without Stand (kg): 4.2

Gross (kg): 10.6

Dimensions (imperial) (wxhxd)

Packaging (in.): 28.7 x 20.3 x 6.3

Physical (in.): 24.13 x 16.72~21.44 x 8.26

Physical Without Stand (in.): 24.13 x 14.46 x 2.26

Dimensions (metric) (wxhxd)

Packaging (mm): 730 x 515 x 159

Physical (mm): 612.94 x 424.73~544.55 x 209.91

Physical Without Stand (mm): 612.94 x 367.23 x 57.5

General

Regulations: cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, NOM, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, BSMI, RCM, VCCI, PSE(Adaptor)

PACKAGE CONTENTS: VP2788-5K x1, 3-pin Plug (IEC C13 / CEE22) x1, DisplayPort Cable (v1.4; Male-Male) x1, HDMI Cable (v2.1; Male-Male) x1, TBT4   Cable (Male-Male) x1, USB Type-C to Type-A 3.2 Gen2 Cable (Male-Male) x1, AC/DC Adapter x1, Quick Start Guide x1

Recycle/Disposal: Please dispose of in accordance with local, state   or federal laws.

Power Management: Energy Star standards, EPEAT
