Dimensions

8.69 in. L x 6.98 in. W x 5.93 in. H

220.8 mm L x 177.5 mm W x 150.7 mm H

Weight

2.98 lbs./1.35 kg

Label Length

Minimum: 0.25 in./6.35 mm

Maximum: 39.0 in./991 mm

Media Width

0.585 in./15 mm to 4.25 in./108 mm

Media Roll Size

Maximum outer diameter: 5.00 in./127 mm

Core inner diameter: 0.5 in./12.7 mm and

1.0 in./25.4 mm standard, 1.5 in./38.1, 2.0 in./50.8 mm and 3.0 in./76.2 mm using optional adapters

Media Thickness

0.003 in. (0.08 mm) min.;

0.0075 in. (0.19 mm) max.

Media Types

Roll-fed or fan-fold, die cut or continuous with or without black mark, tag stock, continuous receipt paper, and wristbands

Ribbon Outside Diameter

2.6 in./66 mm (300 m); 1.34 in./34 mm (74 m)

Ribbon Standard Length

984 ft. /300 m; 243 ft. /74 m

Ribbon Ratio

1:4 ribbon to media (300 m)

1:1 ribbon to media (74 m)

Ribbon Width

1.33 in./33.8 mm–4.3 in./109.2 mm

Healthcare

Our healthcare models have a white color scheme, healthcare-compliant power supply, disinfectant-ready, easy-to-clean plastics, a sealed button interface, and UV-resistant housing

Media Handling

Dispenser/Peeler: label peel and present with label present sensor (field installable)

Cutter (field installable)

Communications

Factory installed: Ethernet 10/100, dual radio Wi-Fi 5 (802.11ac) and Bluetooth 4.1; dual radio Wi-Fi 6 (802.11ax) and Bluetooth 5.3 (MIMO)

Field   installable: Ethernet 10/100, dual radio Wi-Fi 5 (802.11ac) and Bluetooth 4.1; dual radio Wi-Fi 6 (802.11ax) and Bluetooth 5.3 (SISO); Serial RS-232 auto-sensing

Battery

Provides   power to the printer to support a full shift of printing at maximum print speed; supports all media handling options

Carrying Case*

Carrying   case with shoulder strap and handles makes it easy to bring your desktop printer and battery to the point of application

* Does not fit   when cutter or peeler attached.

Enclosed Power Supply

Attached   power supply accessory for cord-free installation of the ZD421

Keyboard Display Unit

ZKDU   keyboard display unit for stand-alone printing solution

Mounting Adapter Bracket

Enables   printer to be mounted in same location as previous models including GK420 and   LP/TLP2824

Barcode Ratios

2:1 and 3:1

1D Barcodes

Code 11, Code 39, Code 93, Code 128, ISBT-128, UPC-A, UPC-E, EAN-8, EAN-13, UPC and EAN 2-or 5-digit extensions, Plessey, Postnet, Standard

2-of-5, Industrial 2-of-5, Interleaved 2-of-5, Logmars, MSI, Codabar and Planet Code

2D Barcodes

Codablock, PDF417, Code 49, DataMatrix, MaxiCode, QR Code, MicroPDF, Aztec

Fonts and Graphics

16 resident expandable ZPL II bitmap fonts, two resident scalable ZPL fonts, five resident expandable EPL2 fonts, native open-type font support, Unicode compliant. China units include SimSun simplified Chinese font

64 MB user available non-volatile memory,

8 MB user available SDRAM

Printers Supplies

For industry-leading quality, service and thermal printing expertise, choose Zebra Certified Supplies to ensure consistent, optimized performance for your Zebra printer.

Regulatory

IEC 60950-1, IEC 62368-1, EN55022 Class B, EN55024, EN55035, EN61000-3-2, EN61000-3-3, FCC Class B, ICES-003, FCC 15.209; 15.247(d), IC RSS 247, EN 300 328, EN 301 893, EN 62311, cTUVus CE Marking, VCCI, C-Tick, S-Mark, CCC, CU, BSMI, KCC, SABS, IN-Metro, BIS, NOM

Environmental Compliance

• RoHS Directive 2011/65/EU; Amendment 2015/863

• REACH SVHC 1907/2006

Included In The Box

Printer, empty ribbon take-up core (0.5 in., thermal transfer models only) AC power supply, power cord(s), USB cable, Quick Start Guide, Regulatory Guide

ZD421 Thermal Transfer includes (2) 300 m ribbon core adapters for non-Zebra ribbon and additional empty ribbon take-up core (1 in.)
