Antennas
1 x 5 GHz: Maximum gain 3.4 dBi 2 x 2.4 GHz&5 GHz: Maximum gain 4.7 dBi for 2.4 GHz, 4.3 dBi for 5 GHz
MU-MIMO
2×2: 2 2.4 GHz 3×3: 2 5 GHz Frequency Bands 2.4 GHz radio: 2,400–2,483.5 MHz. 5 GHz radio: 5,150–5,895 MHz *Not all frequency bands can be used in all regions Channel Bandwidth HT 20/40, VHT 20/40/80, HE 20/40/80/160 Wi-Fi Data Rates 5G: IEEE 802.11ax: 7.3 Mbps to 2,402 Mbps IEEE 802.11ac: 6.5 Mbps to 1,732 Mbps IEEE 802.11n: 6.5 Mbps to 300 Mbps IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 2.4G: IEEE 802.11ax: 7.3 Mbps to 573.5 Mbps IEEE 802.11n: 6.5 Mbps to 300 Mbps IEEE 802.11b: 1, 2, 5.5, 11 Mbps IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps *Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment and mix of devices in the network Maximum TX Power 2.4G: 24 dBm 5G: 26 dBm *Maximum power varies by country, frequency band and MCS rate Receiver Sensitivity 2.4G 802.11b: -96 dBm@1 Mbps, -88 dBm@11 Mbps; 802.11g: -93dBm@6 Mbps, -75 dBm@54 Mbps; 802.11n 20 MHz: -73 dBm@MCS7; 802.11n 40 MHz: -70 dBm@MCS7; 802.11ax 20 MHz: -60 dBm@MCS11; 802.11ax 40 MHz: -58 dBm@MCS11; 5G 802.11a: -92 dBm@6 Mbps, -74 dBm@54 Mbps; 802.11n 20 MHz: -73 dBm@MCS7; 802.11n 40 MHz: -70 dBm@MCS7; 802.11ac 20 MHz: -67 dBm@MCS8; 802.11ac 40 MHz: -63 dBm@MCS9; 802.11ac 80 MHz: -59 dBm@MCS9; 802.11ax 20 MHz: -60 dBm@MCS11; 802.11ax 40 MHz: -58 dBm@MCS11; 802.11ax 80 MHz: -56 dBm@MCS11; 802.11ax 160 MHz: -52 dBm@MCS11; |
