SPECIFICATIONS: Network Protocols | IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3af/at/bt, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1d, IEEE 802.1w, IEEE 802.1s, IEEE 802.1x | Memory | 256MB RAM 8MB Nor Flash, 128MB Nand Flash | Jumbo Frame (Bytes) | 12288 | PoE Standards | IEEE 802.3af/at/bt | Gigabit Ports | 8x 2.5G | SFP+ Ports | 2 (To Support DAC, cable must be ≤ 5m) | Maximum Amount of Supported Modules | SM-10G: 2 MM-10G: 2 RJ45-10G: 2 | Console | 1 | Link Aggregation Groups | 32 | # of PoE Ports | 8 | Integrated Power Supply | 280W(54V/5.19A) | External Redundant Power Supply (RPS) | / | Maximum Output Power Per PoE Port | 60W | Max Total PoE Output Power | 240W | Surge Protection | ± 6KV CM and DM for power ± 4KV CM for network ports | ESD | ± 12KV for contact discharge | Auxiliary Ports | 1x Reset Pinhole | Forwarding Mode | Store-and-forward | Total non-blocking throughput | 40Gbps | Switching Capability | 80Gbps | Forwarding Rate | 59.52Mpps | Packet Buffer | 12Mb | Network Latency | <4µs | Stacking | Yes, up to 4 devices | Switching | • 16K MAC addresses, including static, dynamic and filtering MAC address • 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, MAC-based VLAN, Protocol-based VLAN • Voice VLAN including auto voice VLAN, tagged OUI and untagged OUI • Private VLAN • 16 VLAN virtual interface with 9216 MTU • GVRP (pending) • 1K ARP/NDP • Spanning tree, 32 instances for STP/RTSP/MSTP/PVST(+)/RPVST(+) • ERPS (pending) | Routing | • 512 (IPv4)/128(IPv6) routes • 32 (IPv4)/32(IPv6) static routing • Policy routing (pending) • Dynamic routing, including RIP, RIPng, OSPF, OSPFv3, BGP and IS-IS(pending) • Routing policy • VRRP(pending) | Multicast | • IGMP Snooping with IGMPv2 and IGMPv3, 256 IGMP Snooping groups • MLD Snooping with MLDv1 and MLDv2, 256 MLD Snooping groups • MVR | QoS/ACL | • Port priority • Priority mapping • Queue scheduling, including SP, WRR, WFQ, SP-WRR and SP-WFQ • Traffic shaping • Rate limit • 2K ACL for Ethernet, IPv4 and IPv6 | DHCP | DHCP server, DHCP relay, Option 82, 60, 160 and 43 | Maintenance | • CPU and memory monitoring • Fault detection and alarm for power supply and fan • SNMP including SNMPv1, SNMPv2c, SNMPv3 • RMON • LLDP&LLDP-MED • Backup and restore • Syslog • Diagnostics including Ping, Traceroute, Mirroring including SPAN and RSPAN, UDLD (pending) and copper test • Upgrade via FTPS / TFTP / HTTP / HTTPS or local upload, mass provisioning using DHCP Option / TR-069 (pending) / GDMS Networking / GWN Manager / GWN Series Routers | Security | • User hierarchical management and password protection, HTTPS, SSH, Telnet • Identity authentication including 802.1X and MAC authentication • AAA authentication including RADIUS, TACACS+ • Storm control • Port isolation, port security, sticky MAC • Filtering MAC address • IP/IPv6 source guard, DoS attack prevention, ARP inspection • DHCP/DHCPv6 Snooping • Loop protection including BPDU protection, root protection and loopback protection • Kensington Security Slot (Kensington Lock) support | Mounting | Desktop, or Rack-Mount (rack-mounting kits included) | System LEDs | 1x tri-color LED for device tracking and status indication | Power Supply LEDs | / | PoE Powered LEDs | 8x yellow-color LEDs | Data Transferring LEDs | 10x green-color LEDs | Fan | 2 | Environmental | Operation: 0°C to 45°C, humidity 10% to 90% RH(Non-condensing) Storage: -10°C to 60°C, humidity: 10% to 90% RH(Non-condensing) | Dimensions | 330mm(L)x175mm(W)x44mm(H) | Unit Weight | 1.9Kg | Package Content | 1x Switch 1x 1.2m AC Cable 1x 25cm Ground Cable 4x Rubber Footpads 1x Power Cord Anti-Trip 2x Extended Rack-Mounting Kits 8x Screws(KM 3*6) 1x Simplified Quick Installation Guide 1x Regulatory Paper | Compliance | FCC, CE, RCM, IC |
|
