SPECIFICATIONS: Network Protocols | IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3ax, IEEE 802.3x, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x | PoE Standards | / | Gigabit Ports | 48 | 10G SFP+ Ports | 6 Note: Supports DAC cables up to 5 m | Maximum Number of Supported Modules | SM-10G: 6 MM-10G: 6 RJ45-10G: 3 | Console | 1 | PoE Ports | / | Integrated Power Supply | 60 W | Maximum Output Power Per PoE Port | / | Max Total PoE Output Power | / | PoE Standards | / | Surge Protection | ±6 kV CM and DM for power ±4 kV CM for network ports | ESD | ±12 kV for contact discharge | Other Ports | 1 × Reset Pinhole | Forwarding Mode | Store-and-forward | Total Non-Blocking Throughput | 108 Gbps | Switching Capability | 216 Gbps | Forwarding Rate | 160.704 Mpps | Packet Buffer | 16 Mb | Network Latency | <4 µs | Switching | • 32K MAC addresses, including static, dynamic, filtering and sticky MAC address • 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, MAC-based VLAN, protocol-based VLAN, QinQ • Voice VLAN including auto voice VLAN, tagged OUI and untagged OUI • 32 VLAN virtual interface with 9216 MTU • 1K ARP/NDP • 32 link aggregation • Spanning tree, 64 instances for STP/RTSP/MSTP/PVST(+)/RPVST(+) | Routing | 32(IPv4)/32(IPv6) static routing, which support user-defined static routing entries | Multicast | • IGMP Snooping with IGMPv2 and IGMPv3, 512 IGMP Snooping groups • MLD Snooping with MLDv1 and MLDv2, 512 MLD Snooping groups • MVR | QoS/ACL | • Port priority • Priority mapping • Queue scheduling, including SP, WRR, WFQ, SP-WRR and SP-WFQ • Traffic shaping • Rate limit • 256 ACL for Ethernet, IPv4 and IPv6 with 4K total ACEs | DHCP | DHCP server, DHCP relay, DHCP Option 82, 60, 160 and 43 | Maintenance | • CPU and memory monitoring • Fault detection and alarm for fan • SNMP including SNMPv1, SNMPv2c, SNMPv3 • RMON • LLDP & LLDP-MED • Backup and restore • Syslog • Alert • Diagnostics include Ping, Ping Watchdog, Traceroute, Port Mirroring (SPAN and RSPAN), UDLD (TBD), copper testing, fiber module monitoring, and one-click debugging • Upgrade via FTPS / TFTP / HTTP / HTTPS or local upload, mass provisioning using DHCP Option / TR-069 (pending) / GDMS Networking / GWN Manager / GWN Series Routers | Security | • User hierarchical management and password protection, HTTPS, SSH, Telnet • Identity authentication including 802.1X and MAC authentication • AAA authentication including RADIUS, TACACS+ • Storm control • Port isolation, port security, sticky MAC • Filtering MAC address • IP/IPv6 source guard, DoS attack prevention, ARP inspection • DHCP/DHCPv6 Snooping • Loop protection including BPDU protection, root protection and loopback protection • Kensington Security Slot (Kensington Lock) support • Firmware signature | Mounting | Desktop, Rack Mount (rack mounting kits included) | LEDs | 1 × tri-color LED for device tracking and status indication 54 × green LEDs for data transferring | Fan | 3 | Environmental | Operating Temperature: 0 °C to 45 °C (32 °F to 113 °F ); Operating Humidity: 10%–90% (RH), non-condensing Storage Temperature: -10 °C to 60 °C (14 °F to 140 °F ), Storage Humidity: 10%–90%, non-condensing | Dimensions | 440 mm × 301 mm × 44 mm (17.32″ × 11.85″ × 1.73″) (L × W × H) | Unit Weight | 4.0 kg (8.82 lb) | Package Content | 1 × Switch, 1 × Power Adapter, 1 × 1.2 m (3.94 ft) AC Cable of 10 A, 1 × 25 cm (9.84″) Ground Cable, 1 × Power Cable Clamp, 1 × Simplified Quick Installation Guide, 1 × Regulatory Information, 2 × Rack-Mounting Kits, 8 × Flat Head Machine Screws (M3 × 6 mm), 4 × Rubber Footpads | Compliance | FCC, CE, RCM, IC, UKCA |
|
