SPECIFICATIONS: Network Protocols | IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ad, IEEE 802.3x,IEEE 802.1p, IEEE 802.1Q, IEEE 802.1d, IEEEc802.1s, IEEE 802.1w, IEEE 802.1x | PoE Standards | IEEE 802.3af/at/bt | Gigabit Ports | 48 | 10G SFP+ Ports | 6 Note: Support DAC cable, and must be ≤ 5m | Maximum Amount of Supported Modules | SM-10G: 6 MM-10G: 6 RJ45-10G: 3 | Console | 1 | # of PoE Ports | 48 | PSUs | 1 PSU of 70W by default, support 1 Hot swap PSU(Purchased Separately) | Maximum Output Power Per PoE Port | 60W(1-8,PoE++) 30W(9-48) | Max Total PoE Output Power | 740W with 1 PSU | PoE Standards | IEEE 802.3af/at/bt | Surge Protection | ± 4KV CM and ± 2KV DM for power ± 4KV CM for network ports | ESD | ± 12KV for contact discharge | Auxiliary Ports | 1x Reset Pinhole | Forwarding Mode | Store-and-forward | Total non-blocking throughput | 108Gbps | Switching Capability | 216Gbps | Forwarding Rate | 160.704Mpps | Packet Buffer | 16Mb | Network Latency | <4µs | Switching | • 32K MAC addresses, including static, dynamic, filtering and sticky MAC address • 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, MAC-based VLAN, protocol-based VLAN, QinQ • Private VLAN • Voice VLAN including auto voice VLAN, tagged OUI and untagged OUI • 32 VLAN virtual interface with 9216 MTU • 2K ARP/NDP • GVRP(pending) • 32 link aggregation • Spanning tree, 64 instances for STP/RTSP/MSTP/PVST(+)/RPVST(+) • ERPS (pending) | Routing | • 12K(IPv4)/4K(IPv6) routes • 32(IPv4)/32(IPv6) static routing • Policy routing (pending) • Dynamic routing, including RIP, RIPng, OSPF, OSPFv3 and BGP • Routing Policy • VRRP(pending) | Multicast | • IGMP Snooping with IGMPv2 and IGMPv3, 256 IGMP Snooping groups • MLD Snooping with MLDv1 and MLDv2, 256 MLD Snooping groups • MVR | QoS/ACL | • Port priority • Priority mapping • Queue scheduling, including SP, WRR, WFQ, SP-WRR and SP-WFQ • Traffic shaping • Rate limit • 4K ACL for Ethernet, IPv4 and IPv6 | DHCP | DHCP server, DHCP relay, DHCP Option 82, 60, 160 and 43 | Maintenance | • CPU and memory monitoring • Fault detection and alarm for power supply and fan • SNMP including SNMPv1, SNMPv2c, SNMPv3 • RMON • LLDP&LLDP-MED • Backup and restore • Syslog • Diagnostics including Ping, Traceroute, Mirroring including SPAN and RSPAN, UDLD(pending) and copper test • Upgrade via FTPS / TFTP / HTTP / HTTPS or local upload, mass provisioning using DHCP Option / TR-069(pending) / GDMS Networking / GWN Manager / GWN router | Security | • User hierarchical management and password protection, HTTPS, SSH, Telnet • Identity authentication including 802.1X authentication and MAC authentication • AAA authentication including RADIUS, TACACS+ • Storm control • Port isolation, port security, sticky MAC • Filtering MAC address • IP/IPv6 source guard, DoS attack prevention, ARP inspection • DHCP/DHCPv6 Snooping • Loop protection including BPDU protection, root protection and loopback protection • Kensington Security Slot (Kensington Lock) support | Mounting | Desktop, or Rail-Mount (rack-mounting kits included) | LEDs | 1x tri-color LED for device tracking and status indication 2x bi-color LEDs for per power supply PSU1/2 54x green-color LEDs for data transferring 48x yellow-color LEDs for PoE powered (GWN7816P) | Fan | 4 | Environmental | Operation: 0°C to 45°C, humidity 10-90% RH(Non-condensing) Storage: -10°C to 60°C, humidity: 10% to 90% RH(Non-condensing) | Dimensions | 440mm(L)x380mm(W)x44mm(H) | Unit Weight | 6Kg | Package Content | 1x Switch 1x 1.2m AC Cable 1x 25cm Ground Cable 4x Rubber Footpads 1x Power Cord Anti-Trip 2x Front Rack-Mounting Kits 2x Rear Rack-Mounting Kits 2x Rear Slideways 16x Screws(KM 3*6) 1x Simplified Quick Installation Guide 1x Regulatory Paper | Hot-Swappable PSU | Purchased separately | Compliance | FCC, CE, RCM, IC, UKCA |
|
