Network Protocol | IPv4, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at |
2.5 Gigabit Ethernet Ports | 8 |
10 Gigabit SFP+ Ports | 2, supports 1Gbps/2.5Gbps/10Gbp |
Maximum no. of Supported Modules | SM-10G: 2 MM-10G: 2 RJ45-10G: 1 |
PoE Out Ports | 8 |
Power Supply | Internal 110~220V AC |
PoE Output | Port 1-8 support 802.3af/at standard PoE out: - Up to 30W per port PoE out |
Max Total PoE Output Power | 130W |
Max Output Power per PoE Por | 30W |
Auxiliary Ports | 1x Reset Pinhole |
Forwarding Mode | Store-and-forward |
Total non-blocking throughput | 40Gbps |
Switching Capability | 80Gbps |
Jumbo Frame | 1518/2048/3072/4096/5120/6144/7168/8192/9216 |
Forwarding Rate | 59.52Mpps |
Pack Buffer | 8Mb |
MAC | 16K MAC address capacity |
VLAN | • Supports up to 32 VLANs (out of 4K VLAN IDs) • port-based VLAN, 802.1Q VLAN • DHCP Snooping |
LAG | 5 |
Multicast | IGMP Snooping, Report Message Suppression |
QoS | • Auto prioritization of the incoming port of the packet • Priority Mapping • Queue scheduling, including SP, WFQ • Supports port priority, 802.1P priority, and DSCP priority • Bandwidth control • Rate limit |
DHCP | DHCP client |
Maintenance | Backup and restore, system reboot , Factory Reset, firmware upgrade, Support MAC address search, SNMP, LLDP Monitoring including port statistics, port mirroring cable test, Ping |
Security | • DHCP Snooping • Spanning tree • Loop prevention • PoE Watchdog • Kensington Security Slot (Kensington Lock) support |
Mounting | Desktop/ Wall-Mount/Rack-Mount |
LED Indicators | Per device: Power- Green Per port: Link/Activity - Green GWN7721P Port 1-8: PoE power state - Yellow |
Environmental | Operating Temperature: 0 to 45 °C (32 to 113 °F) Storage Temperature: -20 to 60 °C (-4 to 140 °F) Operating Humidity: 10% to 90% Non-condensing Storage Humidity: 10% to 90% Non-condensing |
Dimensions (L x W x H) | Unit: 280 x 180 x 44mm Package: 361 x 195.5 x 52mm |
Enclosure | Metal |
Weight | Unit: 1.45KG Entire Package: 2.06KG |
Package Content | 1x Switch, 1x 1.2m(10A) AC Cable, 1x Ground Cable, 4x Rubber Feet, 2x Lug Ear, 1x QIG |
Compliance | FCC, CE, RCM, IC |
