CPU | Dual ARM Cortex A53 1GHz |
Memory and NAT Sessions | 256MB RAM, 256MB Flash, 30K NAT sessions |
Network Interfaces | 2x 2.5 Gigabit SFP ports and 4x Gigabit Ethernet ports *All ports support WAN/LAN configurable |
NAT Throughput | 2.2Gbps |
IPsec VPN Throughput | 530Mbps |
Auxiliary Ports | 1x USB 2.0 port, 1x Reset Pinhole |
Mounting | Desktop and wall mounting |
LEDs | 8x single-color LEDs for device tracking and status indication |
Connection Type | DHCP, Static IP, PPPoE, PPTP, L2TP |
Network Protocols | IPv4, IPv6, IEEE802.1Q,IEEE 802.1p, IEEE802.1x, IEEE802.3, IEEE 802.3u, IEEE 802.3x,IEEE802.3ab |
QoS | • VLAN, TOS • Support multiple traffic classes, filter by port, IP address, DSCP, and policing • App Qos • VoIP Prioritization |
Firewall | DDNS, Port Forwarding, DMZ, UPnP, Anti-DoS, traffic rules, NAT, ALG, TURN Service |
Security | • Application/protocol monitoring and traffic statistics • Content filtering: Supports Application/URL/DNS/Web Content Filtering • Safe search |
VPN | • IPsec VPN Client-to-Site / Site-to-Site • PPTP VPN Server / Client • L2TP Client-to-Site • OpenVPN® Server / Client • WireGuard® • IPSec Encryption: DES, 3DES, AES • IPSec Authentication: MD5, SHA-1, SHA2-256 • IPSec Key Exchange: Main/Aggressive Mode, Pre-shared Key, DH Groups 1/2/5/14 • IPSec Protocols: ESP • IPSec NAT Traversal • OpenVPN® Encryption: AES, DES • OpenVPN® Authentication: MD5, SHA-1, SHA2-256, SHA2-384, SHA2-512 • OpenVPN® Certificate: RSA • PPTP Encrpytion: MPPE 40-bit, 128-bit, IPSec • PPTP/L2TP Authentication: MS-CHAPv1/2 |
Max Concurrent VPN Tunnels | Up to 50 Tunnels |
Network Management | GWN7002 embedded controller can manage itself and up to 100 GWN Aps • GWN.Cloud offers a free cloud management platform for unlimited GWN Routers and GWN APs. • SSH for CLI • Telnet (Pending) • TR-069 • SNMP v1/v2c/v3 |
USB Port Specifications | Supports connections of 4G USB modems with power consumption not exceeding the maximum output for the corresponding hardware version: • Output for hardware version before V2.0A: 0.5A 2.5W • Output for hardware version after V2.0A: 0.8A 4W |
PoE Input | Standard: IEEE 802.3af/at |
PoE Output | 2x PoE out ports Passive 48V or IEEE802.3af |
PoE Power Budget | 24V DC 1A: 12.8W 24V DC 1.5A: 24.8W |
Power & Green Energy Efficiency | Universal power adaptor included: Input: 100-240VAC 50-60Hz Output: 24V DC 1A (24W) |
Environmental | Operation: 0°C to 40°C Storage: -30°C to 60°C Humidity: 10% to 90% Non-condensing |
Physical | Unit Dimension: 210mm(L)x130mm(W)x35mm(H); Unit Weight: 505g Entire Package Dimension: 246mm(L)x235mm(W)x54mm(H); Entire Package Weight: 730g |
Package Content | GWN7002 Router, Universal Power Supply, Network Cable, Quick Installation Guide |
Compliance | FCC, CE, RCM, IC, UKCA |
