Wi-Fi Standards | IEEE 802.11 a/b/g/n/ac (Wave-2) |
SSIDs | 16 SSIDs total, 8 per radio (2.4GHz & 5GHz) |
Concurrent Clients | 100+ |
Basics | Beamforming OFDM 256-QAM Target wake time (TWT) Maximal Ratio Combining (MRC) Space-Time Block Coding (STBC) Low-density Parity-Check (LDPC) 802.11 Dynamic Frequency Selection (DFS) BSS coloring |
SSID | Hidden Restrict access and improve wireless network security by SSID hiding |
Port Aggregation | Multiple uplink ports for port aggregation to increase uplink bandwidth |
Multicast/Broadcast Suppression | Multicast/Broadcast enable optimization with ARP proxy |
Multicast Enhancement | Convert multicast data into unicast data for transmission |
Bandwidth Limiting | Support SSID/Client/MAC/IP-based rate limiting |
Band Steering/Client Steering | Guide client to the frequency band with more abundant spectrum resources |
RRM | Dynamically assign radio power, channel |
VPN | L2TPv3 |
VLAN | Support interface/SSID/MAC binding VLAN based Management VLAN Dynamic VLAN |
Time Policy | Track the time that the client connects to Wi-Fi, Support setting the amount of time for the client to connect to Wi-Fi and the reconnec type after a timeout |
Schedule | Support SSID, LED, Reboot schedule |
Bridge | Support |
Mesh | 2.4GHz, 5GHz, 2.4GHz&5GHz |
Hotspot2.0 | Support |
Wireless Roaming | 802.11k, 802.11v, 802.11r Layer 2 roaming |
IPv4 | Static or DHCP |
IPv6 | Static or DHCP |
DHCP | Support server/client/relay |
NAT | NAT Pool |
LLDP | Link Layer Discovery Protocol, discovering and identifying other LLDP enabled devices and neighboring devices in the network |
802.1x authentication | Support |
MAC authentication | Use client MAC address as the username and password for access control through the RADIUS server |
PPSK | PPSK with/without RADIUS |
Captive Portal | Support radius/social login/vouchers/password/SAML SSO/active directory authentication |
Encryption | Open system OSEN WPA2-PSK (personal) WPA2-802.1x (enterprise) WPA3-SAE (personal) WPA3-802.1x (enterprise) WPA/WPA2, WPA2/WPA3 anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device |
Forwarding Security | MAC filtering Client isolation OS filtering |
WIDS | Inbound/outbound traffic rules Rogue AP detection and containment ARP attack defense ND attack defense |
QoS | 802.11e/WMM,802.1p, 802.1q, TOS |
Local Web | Embedded controller can manage up to 50 local GWN APs |
GDMS Networking | A free cloud management platform for unlimited GWN APs |
GWN Manager | Premise-based software controller for up to 3,000 GWN APs |
GWN APP | Integrate GDMS Networking and GWN Manager to manage GWN APs via the APP |
Management Protocol | TR-069 SNMP |
